Landing Gear
Outer Housing

Protection Angle
(Weld on Assembly)

Coil Cord/
Protection
Tube
Assembly

Aft

Load Pin/Sandshoe
Assembly

Applications

43

Figure 4-44. Typical Load Pin Landing Gear Installation Outboard View
