Page 51

320IS Installation Manual - Print Formatting
45
Figure 6-1. PFORMT Menu
6.2.3
Using Revolution®
The Revolution configuration utility provides a print formatting grid with a tool bar. The grid allows you to
construct the print format without the formatting commands (
command methods. Using Revolution, you can type text directly into the grid, then select weight value fields from
the tool bar and place them where you want them to appear on the printed ticket.
Figure 6-2. Revolution Ticket Editor
GFMT
Display first 6
characters of format
Same as GFMT
NFMT
Display and edit
active character and
ASCII value
Delete active
character
Scroll right in format string
Scroll left in format string
Increment ASCII value of active character
Decrement ASCII value of active character
Press
to insert a space
before the active character
XXXXXXX
XXXXXXX
XXXXXXX
XXXXXXX
VERS
ALGOUT
DIG IN
PROGRM
PFORMT
SERIAL
CALIBR
CONFIG
FORMAT
XXXXXXX
SETPNT
