320IS Installation Manual
PWRUPMD
Power up mode
GO, DELAY
SAMPSIZ
Sample size
5, 10, 20, 50, 100, PCWGT
CNTMOD
Count mode access
DISABLE, ENABLE
UID
Unit identifier
000000–999999
STNDBY
Standby
0-255
DATEFMT
Date format
MMDDYY, DDMMYY, YYMMDD, YYDDMM
DATESEP
Date Separator
SLASH, DASH, SEMI
TIMEFMT
Time format
12HOUR, 24HOUR
TIMESEP
Time separator
COLON, COMMA
Command
Description
Values
GFMT
Gross demand print format string
See Section 6.0 on page 43 for detailed information
NFMT
Net demand print format string
CFMT
Count demand print format
Table 5-8. PFORMT EDP Commands
Command
Description
Values
DIGIN1
DIGIN2
DIGIN3
DIGIN4
Digital input function
OFF, ZERO, TARE, NT/GRS, UNITS, DSPTAR, PRINT, CLRCN,
KBDLOC, HOLD, CLRTAR, CLRACC, ACCUM, ENTER, GROSS,
NET, PRIM, SEC, NEWID
Table 5-9. DIG IN EDP Commands
EDP digital output commands only function in TEST mode (see Figure 7-4 on page 55).
Command
Description
DON#n
Set digital output n on
DOFF#n
Set digital output n off
DOFF#0
Set all digital outputs off
DON#0
Set all digital outputs on
For commands ending with “#n”, n is the digital output (1–4) being set on or off.
Table 5-10. DIG OUT EDP Commands
Command
Description
Values
AO1.SOURCE
Analog output source
GROSS, NET
AO1.OFFSET
Zero offset
0%, 20%
AO1.ERRACT
Error action
FULLSC, HOLD, ZEROSC
AO1.MIN
Minimum value tracked
0–999 990
AO1.MAX
Maximum value tracked
0–999 990
AO1.TWZERO
Zero calibration
0–65535
AO1.TWSPAN
Span calibration
0–65535
Table 5-11. ALGOUT 1 EDP Commands
Command
Description
Values
Table 5-7. PROGRM EDP Commands (Continued)
