38 320IS Installation Manual
5.1.2 Reporting Commands
Reporting commands (see Table 5-2) send specific information to the EDP port. These commands can be used in
both setup mode and normal mode.
5.1.3 The RESETCONFIGURATION Command
The RESETCONFIGURATION command can be used to restore all configuration parameters to their default
values. Before issuing this command, the indicator must be placed in test mode (press and hold setup switch until
TEST
is displayed).
This command is equivalent to using the DEFLT function on the TEST menu. See Section 7.8 on page 55 for more
information about test mode and using the TEST menu.
All load cell calibration settings are lost when the RESETCONFIGURATION command is run.
5.1.4Parameter Setting Commands
Parameter setting commands allow you to display or change the current value for a particular configuration
parameter See Tables 5-3 through 5-12 for more information on menu parameters.
Current configuration parameter settings can be displayed in either setup mode or normal mode using the following
syntax:
command
Most parameter values can be changed in setup mode only. Use the following command syntax when changing
parameter values:
command=value
where
value
is a number or a parameter value. Use no spaces before or after the equal (=) sign. If you type an
incorrect command or value, the display reads
??
. Changes to the parameters are saved as they are entered but
typically do not take effect until you exit setup mode.
For example, to set the motion band parameter to 5, type the following:
MOTBAND=5D
Command Function
DUMPALL List all parameter values
IOVERSION Display I/O Module software version
P Display current displayed weight with units
identifier. See Section 7.2.1 on page 47 for
more information.
ZZ Display current weight and annunciator
status. See Section 7.2.2 on page 47 for
more information.
S Display one frame of stream format
Table 5-2. EDP Reporting Commands
Command Description Values
GRADS Graduations 1–100 000
ZTRKBND Zero track band OFF, 0.5D, 1D, 3D
ZRANGE Zero range 1.9%, 100%
MOTBAND Motion band 1D, 2D, 3D, 5D, 10D, 20D, OFF
OVRLOAD Overload FS+2%, FS+1D, FS+9D, FS
DIGFLTRX* Digital filtering 1, 2, 4, 8, 16, 32, 64
DFSENS Digital filter cutout sensitivity 2OUT, 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
DFTHRH Digital filter cutout threshold NONE, 2DD, 5DD, 10DD, 20DD, 50DD, 100DD, 200DD, 250DD
TAREFN Tare function BOTH, NOTARE, PBTARE, KEYED
SMPRAT Sample rate 15Hz, 30Hz, 60Hz, 7.5Hz
NOTE: * X = 1, 2, 3
Table 5-3. CONFIG EDP Commands
Note
