Kontron pITX-E38 - Manual (Page 40)

KTD-N0904-D Page 38 BIOS - Main
pITX-E38 Users Guide
Function Selection Description
NumLock:
On
Off
Select Power-on state for NumLock.
Timeout 0 Note 1 Number of seconds that P.O.S.T will wait for the user
input before booting.
CSM Support
No
Yes
Compatibility Support Module that provides backward
compatibility services for legacy BIOS services, like
int10/int13, dependent OS.
Quick Boot
Disabled
Enabled
Enable/Disable quick boot.
Diagnostic Splash Screen
Disabled
Enabled
If you select ‘Enabled’ the diagnostic splash screen
always displays during boot. If you select ‘Disabled’
the diagnostic splash screen does not display unless
you press HOTKEY during boot.
Diagnostic Summary Screen Disabled
Enabled
Display the diagnostic summary screen during boot.
BIOS Level USB
Disabled
Enabled
Enable/Disable all BIOS support for USB in order to
reduce boot time. Note that this will prevent using a
USB biometric scanner such as a finger print reader
to control access to setup, but does not prevent the
operating system from supporting such hardware.
Console Redirection
Disabled
Enabled
Enable/Disable Universal Console Redirection.
Allow Hotkey in S4 resume
Disabled
Enabled Enable hotkey detection when system resuming from
Hibernate state.
UEFI Boot
Disabled
Enabled
Enable the UEFI boot.
Legacy Boot
Disabled
Enabled
Enable the Legacy boot.
Boot in Legacy Video Mode
Disabled
Enabled
Enable to force the display adapter to switch the
video mode to Text Mode 3 at the end of BIOS POST
for non-UEFI boot mode (Legacy Boot). Some legacy
software, such as DUET, requires that the BIOS
explicitly enter text video mode prior to boot.
Load OPROM
All
On Demand
Load all OPROMs or on demand according to the boot
device.
Note 1: Use either digit keys to enter value (0 – 99) or +/- keys to increase/decrease value.
