KTD-N0904-D Page 9 System Specification
pITX-E38 Users Guide
Environmental
Conditions
Operating:
-25ºC to 75ºC operating temperature. It is the customer’s responsibility to provide
sufficient airflow around each of the components to keep them within allowed
temperature range.
10% to 90% relative humidity (non-condensing)
Storage:
-20°C to 70°C; lower limit of storage temperature is defined by specification
restriction of on-board BR2032 battery. Board with battery has been verified for
storage temperature down to -40°C by Kontron.
5% to 95% relative humidity (non-condensing)
Electro Static Discharge (ESD) / Radiated Emissions (EMI):
All Peripheral interfaces intended for connection to external equipment are ESD/ EMI
protected.
EN 61000-4-2:2000 ESD Immunity
EN55022:2006+A1:2007 class B Generic Emission Standard.
Safety:
IEC 60950-1: 2005, 2nd Edition
UL 60950-1
CSA C22.2 No. 60950-1
Product Category: Information Technology Equipment Including Electrical Business
Equipment
Product Category CCN: NWGQ2, NWGQ8
File number: E194252
Shock:
IAW IEC 60068-2-27, Test Ea, shock, 18 shocks 3 per axis, 6 directions.
Shock pulse 50g, 11ms halfsine.
Bump:
IAW IEC 60068-2-29, Test Eb, Bump, 3000 bumps, 500 per axis, 6 directions.
Half Sine Waveform Acceleration 2g; Pulse Duration 11ms.
Vibration:
IAW IEC 60068-2-64, Test Fh, Random Vibration. 90 min per axis, 3 axes, at 1.9 grms,
with PSD: 10-20 Hz: 0.05 g²/Hz and 20-500 Hz: -3dB/octave.
Theoretical MTBF:
414.670 / 183.190 hours @ 40°C / 75°C. Note that these values are without the active
cooler used on the pITX-E3845 (see next page).
Restriction of Hazardous Substances (RoHS):
All boards in the pITX-E38 family are RoHS compliant.
Capacitor utilization:
Solid Capacitors with Conductive Polymer rated for 105 °C used on board.
