KTD-N0904-D Page 34 On-board and Mating connectors
pITX-E38 Users Guide
9 On-board - & mating connector types
The Mating connector(s) / Cable Kits(s) which are fitting the On-board connectors are listed in below table.
The highlighted cable kits are included in the “pITX-E38 Cable & Driver Kit” PN 1056-2142 / 1000000021
(Different quantity of each cable kit included, depending on the quantity of onboard connectors).
Connector
On-board Connectors Mating Connectors / Cables
Manufacturer Type no. Manufacturer Type no.
FAN (J25) MOLEX 53047-0310
XDP (J39) MOLEX 52435-2671
SATA0 (J30)
LOTES ABA-SAT-055-K03 Kontron 96079-0000-00-1 (cable)
+5Vin Int. (J24)
JST B4B-XH-A(LF)(SN) Kontron 1055-8061 (cable)
USB2 (J12)
USB3 (J11)
MOLEX 53047-0410 Kontron 96054-0000-00-2 (cable)
EFCO 1250S-04TW
LVDS (J10)
DON CONNEX C44-40BSBC1-G Don Connex A32-40-C-G-B-1
WIESON
TECHNOLOGIES
G2124-03200101-00 Kontron 910000005
Hon Kon Technology HB12-220-VFS-20R Kontron 821515 (cable)
SAMTEC SHF-120-01-F-D-SM-K-TR Kontron 821155 (cable)
COM1 (J21)
COM2 (J22)
MOLEX 53261-0571 Kontron 1055-8059 (cable)
Audio (J28)
MOLEX 53261-0671 Kontron 96063-0000-00-1 (cable)
Ext. Battery (J1)
Wuerth Elektronik 62000211121 Kontron Battery Module
W+P 314-010-002-XX
Always On (J42)
Clear CMOS (J40)
YIMTEX 3291*03SAGR(6T)
TE Connectivity 382575-3 (jumper)
TE Connectivity 382575-2 (jumper)
W+P 351-201-10-00/BF*2 (jumper)
SPI (J41)
MOLEX 53261-0971
FRONTPNL (J5)
MOLEX 87759-1014 Kontron 1055-8065 (cable)
GPIO (J2)
(Battery Module)
PLASTRON LTZ-10S2-B-C/D-F Kontron 1055-8063 (cable)
PLASTRON LTZ-10S2-B-040/028-F
FCI 57102-F06-05ULF
W+P 314-200-010-00
MOLEX 0877581016
Note: In above table, more than one connector can be listed for each type of on-board connector, if they
all have same fit, form and function and are approved by Kontron as an alternative. Please notice that
standard connectors like DP, miniPCIe, Ethernet and USB are not included in the list.
