Power Consumption 3.2
The following items were used in the test setup:
1. Low Power Setup (E3815):
Standard system configuration equipped withInternal graphics, 1x 500GB SATA disk, mSATA 40GB, 1x
SODIMM (2GB Modules), DP Monitor, USB Keyboard & Mouse. 1x 8GB USB2.0 Stick, 1x LAN Gigabit.
Mid Power Setup (E3826):
Standard system configuration equipped withInternal graphics, 1x 500GB SATA disk, mSATA 40GB, 1x
SODIMM (4GB Modules), DP Monitor, USB Keyboard & Mouse. 2x 8GB USB2.0 Stick,1x LAN Gigabit.
High Power Setup (E3845):
Standard system configuration equipped withInternal graphics, 1x 500GB SATA disk, mSATA 40GB, 1x
SODIMM (8GB Modules), DP Monitor, LVDS, USB Keyboard & Mouse. 2x 8GB USB2.0 Stick,1x 16GB
USB3.0 Stick,1x LAN Gigabit.
2. Active cooler (High & Mid), Passive cooler (Low)
3. USB Keyboard/Mouse
4. 2.5” SATA HDD external power.
5. Agilent E3634A @ 5V, 4A
6. Lecroy SDA820Zi-A Oscilloscope
7. Lecroy AP015 Current Probe
8. USB Flash 1x 8GB USB 2.0
9. USB Flash 1x 16GB USB 3.0
10. DP Monitor 1200x1600
11. LVDS Display 1200x1600
12. mSATA: 40GB
13. Memory: 8/4/2 GB SODIMM 1333 PC3-10600
Power measurrements:
Low Power Setup (E3815) Mid Power Setup (E3826) High Power Setup (E3845)
DOS Idle
760mA - 3.8W 935mA - 4.675W 1150mA - 5.75W
Windows 7, 3DMARK AE (first scene) +Burn in test 7.1
1320mA - 6.6W 1810mA - 9.05W 2270mA - 11.35W
Windows 7, idle, desktop, no applications running
848mA - 4.24W 1130mA - 5.65W 1250mA - 6.25W
S3 Mode
247mA - 1.235W 255mA - 1.275W 266mA - 1.33W
S4 Mode
239mA - 1.195W 238mA - 1.19W 236mA - 1.18W
S5 Mode
214mA - 1.070W 219mA - 1.095W 228mA - 1.14
Note that power consumption of the
Display and HDD are not included.
