KTD-N0904-D

Page 21

IO-Area Connectors

pITX-E38 Users Guide

DC Power Jack Connector (5Vin Ext.)

6.2

Either the DC Power Jack Connector (5Vin Ext.) or the “5Vin Int.” connector must be used to supply the
board with +5V +/-5%.

The 5Vin Ext. power connector has Vin to the center pin

and mates with Ø 6.3 mm DC Power jack with Ø 2.0

mm pin hole. (DC Connector RA 2mm locking type). Maximum allowed current is 5A.

Warning: Hot Plugging power supply is not supported. Hot plugging might damage the board.

Notes:

To protect the external power lines of peripheral devices make sure that

- the wires have the right diameter to withstand the maximum available current.
- to enclosure of the peripheral device fulfills the fire-protecting conditions of IEC/EN 60950.
