Kontron pITX-E38 - Manual (Page 33)

KTD-N0904-D Page 31 IO-Area Connectors
pITX-E38 Users Guide
XDP (XDP) 7.13
The XDP-CPU (Intel Debug Port for CPU) connector is not mounted and not supported. XDP connector layout
(pads) is located on the backside of PCB and is prepared for the Molex 52435-2671 (or 52435-2672).
Pin Signal Description Type Pull Up/Down Note
1 OBSFN_A0 220R to 1,8V
2 OBSFN_A1
3 GND PWR -
4 NC NC -
5 NC NC -
6 GND PWR -
7 NC NC -
8 NC NC -
9 GND PWR -
10 HOOK0 PMC_RSMRST#
11 HOOK1 PWRBTN#
12 HOOK2 PMC_CORE_PWROK
13 HOOK3 XDP_RTEST#
14 HOOK4 NC
15 HOOK5 NC
16 +1,8V PWR -
17 HOOK6 PLTRST#
18 HOOK7 1,8V_SYS_RESET#
19 GND PWR -
20 TDO 50R to 1,8V
21 TRST# /50R
22 TDI 50R to 1,8V
23 TMS 50R to 1,8V
24 NC NC -
25 GND PWR -
26 TCK0 /50R
