Appendix: Mating Connectors
The Mating connectors / Cables are connectors or cable kits which are fitting the On-board connector.
Connector
Onboard Connectors Mating Connectors
Manufacturer P/N Manufacturer P/N
DisplayPort J3/J4/J43 Foxconn 3VD11203-H7AB-4H
USB10/USB11/USB12/USB13 J14/J15 Lotes ABA-USB-104-K01
ETH1/ETH2 J8 Ude RMT-123AGF1F
USB6/USB7/USB8/USB9 J20 Foxconn UB11123-Q8DF-4F
Audio stack J40 Lotes ABA-JAK-028-K03
Power ATX-BTX J17 Molex 44206-0002 Molex 5557-24R
Power ATX-core J19 Lotes ABA-POW-003-K02 Molex 39-01-2045
Audio Header J41 Molex 87832-2620
Molex
Kontron 51110-2651
821043 (kit)
Power Out J18 Molex 22-23-2041
Molex
Kontron 22-01-2045
1027-3669 (Kit)
USB4/USB5 J16 Foxconn HS1105F-RNP9
SPI J21 Pinrex 512-90-10GBE5
COM1/COM2 J22/J23 Pinrex 512-90-10GBE5
Molex
Kontron 90635-1103
821017 (kit)
LPC J29 Foxconn HC11101-P0
Frontpanel J5 Wieson G2120HT0038-016
Molex
Kontron
90635-1243
821042 (kit)
CPU Fan/System Fan J24/J25 Tyco 1470947-1 Molex 47054-1000
Feature J26
Pinrex 52C-90-44GB00 Don Connex A05c-44-B-G-A-1-G
Foxconn HS5422F Kontron 1052-5885 (kit)
KBD/MSE J27 Molex 22-23-2061
Molex
Kontron 22-01-2065
1053-2384 (kit)
Cable & Driver Kit KTA70M/KTA75 (PN 826600-R11) contains:
2x PN 821017 Cable, COM, 2.54mm, 100mm
1x PN 1052-5885 Cable, Feature 44pol 1 to1, 300mm
1x PN 1053-2384 Bracket Cable 6-Pin to PS2-Kbd-Mse
1x PN 821042 Cable, Front Panel Open-End
1x PN 821043 Cable, Audio Open-End
6x PN 821035 Cable, SATA, 500mm
1x PN 1052-5814 Cable, ATX Power for KTA70M
1x PN 1027-3669 Cable Power Out
for KTA70M
1x PN 821401 Cable+Bracket, USB, 10poled
1x PN 1052-5818 SW,Man&Driver CD,KA70M/KTA75
