KTD-N0861-B

Page 26

Pin Connectors


KTA75/Flex Users Guide

KTA70M/mITX Users Guide


Don’t leave the Clear CMOS jumper in position 1-2, otherwise if power is
disconnected, the battery will fully deplete within a few weeks.

Warning

!

7.5

Jumper area (J34, J35, J36, J37)

The KTA75 has a jumper area containing pin connectors 2.54mm pitch, for up to four jumpers, but normally
only one jumper is used (jumper in the J34 pin 2-3 position, as indicated below).


Function

J#

Jumper in position

1-2

Pin

Jumper in position

2-3

1 2 3

Always On

J37

-

Always On

Clear CMOS

J34

Clear CMOS

Normal (Default)

Audio Short circuit test

J36

Front Right

Front Left

Not mounted

J35

-

-


Always On: is PT not supported.


(None): Not mounted on final version of board. Only mounted on Early Field Test versions of KTA75.

Clear CMOS: is used to erase all customised BIOS settings located in the CMOS RAM storage. If the board has
a booting problem or is unstabile, then Clearing CMOS by moving the Jumper from default position to the

Clear CMOS position for approx. 10 sec. might solve the problem.




Audio Short Circuit Test: is only used in manufacturing test. No jumper should be installed.
