System Specification
KTA75/Flex Users Guide
KTA70M/mITX Users Guide
LAN
Two RJ45 connectors J8 (in REAR-IO area)
•
2x 10/100/1000Mbits/s LAN (ETH1/ETH2) using Intel® Pearsonville xGB PCI Express
Ethernet controller (WGI211ATSLJXZ).
•
PXE Netboot supported.
•
Wake On LAN (WOL) supported
USB
14x USB ports (10x USB2.0 & 4x USB2.0/USB3.0):
2x USB2.0 in Frontpanel Connector J5
2x USB2.0 in USB Internal USB Connector J16
4x USB2.0, USB stack J20 (in REAR-IO area)
2x USB 2.0/USB3.0, Right USB stack J14 ( in REAR-IO area)
2x USB 2.0/USB3.0, left USB stack J15 (in REAR-IO area)
1x USB 2.0 in mPCIe socket J38
1x USB 2.0 in mSATA/mPCIe socket J43
Serial port
2x RS232 pin header (+12V, -12V supply generated by driver circuit)
COM1 2x 5 Pin row J23
COM2 2x 5 Pin row J22
LPC
LPC connector J29
FAN
CPUFAN 4 pin row J25 12V PWM
SYSFAN 4 pin row J24 12V PWM
PS2 Kbd/Mse
1x 6 Pin row Keyboard / Mouse PS2 cable kit interface J27
Power Plug
ATX12V: 1x 4 pole connector J19 (core power) and 1x 24 pole connector J17 ATX/BTX
Battery
Exchangeable 3.0V Lithium battery for on-board Real Time Clock and CMOS RAM.
Manufacturer Panasonic / Part-number CR-2032L/BN, CR2032N/BN or CR-2032L/BE.
Approximate 6 years retention.
Current draw is 4 µA when PSU is disconnected and 0 µA in S0 – S5.
CAUTION: Danger of explosion if the battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Speaker
On-board Speaker Piezo
On-board speaker (Electromagnetic Sound Generator like Hycom HY-05LF)
BIOS
AMI EFI
SPI Connector J21 (for BIOS Recovery)
Clear CMOS J34
Always On J37
OS (planned)
Windows 7 (32 and 64bit)
Windows 8 (32 and 64bit)
Windows XP (32 bit)
DOS
Windows Embedded 7
