PCI Express Settings
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Advanced
PCI Express Device Register Settings
Relaxed Ordering
Extended Tag
No Snoop
Maximu Payload
Maximum Read Request
PCI Express Link Register Settings
ASPM Support
WARNING: Enabling ASPM may cause
some PCI-E devices to fail
Extended Synch
Link Training Retry
Link Training Timeout (uS)
Unpopulated Links
[Disabled]
[Disabled]
[Enabled]
[Auto]
[Auto]
[Disabled]
[Disabled]
[5]
100
[Keep Link ON]
Enables or Disables PCI Express
Device Relaxed Ordering.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
