Kontron KTA75-FLEX - Manual (Page 55)

KTD-N0861-B Page 47 BIOS - Advanced
KTA75/Flex Users Guide
KTA70M/mITX Users Guide
9.2 Advanced
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
► PCI Subsystem Settings
► ACPI Settings
► Trusted Computing
► CPU Configuration
► IDE Configuration
► USB Configuration
► Super IO Configuration
► Hardware Health Configuration
► LAN Configuration
► PCI-E Port
► Network Stack
PCI, PCI-X and PCI Express
Settings.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1227. Copyright © 2012 American Megatrends, Inc
The Advanced (main) menu contains only submenu selections which will be described in more details on
the following pages.
In order to make a selection of a submenu activated the
↑↓ keys until the requested submenu becomes
white color, then activate the .
