8.2 PCIex4 (J6)
The PCIex4 (4-lane PCI Express) is available through a PCIe x16 slot and support PCIe 2.0. The slot can be
used for external PCI Express cards inclusive graphics card. The slot is located nearest the CPU of the board.
Maximum theoretical bandwidth using 4 lanes is 4 GB/s.
Note Type Signal PIN Signal Type Note
+12V B1 A1 GND via 0 ohm
+12V B2 A2 +12V
+12V B3 A3 +12V
GND B4 A4 GND
SMB_CLK B5 A5 NC
SMB_DATA B6 A6 NC
GND B7 A7 NC
+3V3 B8 A8 NC
NC B9 A9 +3V3
SB3V3 B10 A10 +3V3
WAKE# B11 A11 RST#
NC B12 A12 GND
GND B13 A13 PCIE_x16 CLK
PEG_TXP[0] B14 A14 PCIE_x16 CLK#
PEG_TXN[0] B15 A15 GND
GND B16 A16 PEG_RXP[0]
CLKREQ B17 A17 PEG_RXN[0]
GND B18 A18 GND
PEG_TXP[1] B19 A19 NC
PEG_TXN[1] B20 A20 GND
GND B21 A21 PEG_RXP[1]
GND B22 A22 PEG_RXN[1]
PEG_TXP[2] B23 A23 GND
PEG_TXN[2] B24 A24 GND
GND B25 A25 PEG_RXP[2]
GND B26 A26 PEG_RXN[2]
PEG_TXP[3] B27 A27 GND
PEG_TXN[3] B28 A28 GND
GND B29 A29 PEG_RXP[3]
NC B30 A30 PEG_RXN[3]
CLKREQ B31 A31 GND
GND B32 A32 NC
NC B33 A33 NC
NC B34 A34 GND
GND B35 A35 NC
GND B36 A36 NC
NC B37 A37 GND
NC B38 A38 GND
