System Specification
KTA75/Flex Users Guide
KTA70M/mITX Users Guide
Memory
Memory controller is integrated in the AMD eTrinity FS1r2 uPGA 722pin
processor.
Features are:
•
Compliant with JEDEC DDR3 1.5V and (LV-DDR3 1.35V / 1.25 SDRAM, not verified)
specifications
•
Supports DDR3 UDIMM 240pin Using up to 8GB DRAM technology
•
DDR3 1333/1600MT/s (PC3-10600/PC3-12800)
•
From 1GB to 2x 8GB maximum (16GB in total)
Notes: Less than 4GB displayed in System Properties using 32bit OS
(Shared Video Memory/PCI resources is subtracted)
ECC not supported
Flash (BIOS)
32Mbit SPI Flash for dual System BIOS.
Security
Intel® Integrated TPM 1.2 support
Infineon TPM SLB9635TT1.2 (FW 3.17)
IT8516E
Embedded
Controller
KT Feature Connector.
15 Multiplexed (GPIO, DAC, ADC, PWM & TIMER)
Possible 152 GPIO expansion.
Software Watchdog.
Audio Codec
Audio, 7.1 Channel High Definition Audio Codec using the VIA VT1708S codec
Seriel ATA
6x SATA port J9 – J13 & J39, SATA 3.0
1x mSATA J39 (mechanically sharing space with mPCIe slot J38), SATA 3.0
•
RAID 0,1,10 support
Frontpanel
2xUSB, HDD-LED, SYSRST#, SUSLED, PWRBTN#, AUDIO Line/MIC output.
PCI
2x PCI slots (PCI Local Bus Specification revision 2.3 32bit/33MHz)
PCIe
1x PCI Express x16 Slot
1x PCI Express x4 Slot (in mechanically x16 slot)
1x mPCIe Slot J38
1x mPCIe/mSATA J43 (mechanically sharing between mSATA and mPCIe). The mSATA
interface will be selected when a mSATA card are inserted into the mPCIe socket (J43)
DisplayPort
3x DisplayPort connector ( in REAR-IO area)
DP1 J44
DP2 J3
DP0 J4
Optionally Add-On card with 1x DisplayPort
LVDS
Optionally Add-On card (TBD)
Audio Jack
3x Audiojacks stack J40 (in REAR-IO area)
Blue Line-In
Green Speaker
Pink Mic
Audio
Audio Pin header J41
Line-out
Line-in
Surround output: SIDE, LFE, CEN, BACK and FRONT
Microphone: MIC1
SPDIF-OUT (electrical Interface only)
