GS160/320 System Overview

2-13

2.3.5

Power Modules

Two power modules are installed in the QBB backplane.

The main

power module and the auxiliary power module convert 48 VDC to the
various voltages required to power the QBB.

Figure 2–9 Power Modules

PK-0604-99

Main Power Module

Auxiliary Power Module
