Using the System Control Manager 8-11
8.4 Console Device Setup
You can use the SCM from a console device connected to the system or
a modem hookup. As shown in Figure 8–4, local connection is made
from the local port
. You connect remotely from a modem connected
to the modem port .
Figure 8–4 Setups for SCM (PCI Box)
1
2
PK-0650-99
Note: Both the local port and the modem port are set at:
1 start bit, 8 data bits, 1 stop bit, no parity.
Local port defaults: baud rate is 9600, flow control is soft.
Modem port defaults: baud rate is 57600, flow control is hard.
