Series 8750XD Unitized Curtain Wall Installation Instructions

Table Of Contents

SECTION

PAGES

1. General Notes and Guidelines………………………………………………………………………………………………………………………………

2. Parts

Identification…………………………………………………………………………………………………………………………………………….


3. Static Starter Sill Preparation and Installation……………………………..…………………………………………………………………………….

4. Dynamic Starter Sill Preparation and Installation…………………..………………..………………………………………………………………….

5. Intermediate Floor Slab Anchor Installation……………………………………….....………………………………………………………………….

6. Unit Inspection and Preparation for Installation……………………………..….......………………………………………………………………….

7. Setting Units at Static Starter Sills………………………………………………..…....………………………………………………………………….

8. Setting Units at Dynamic Starter Sills………………………………………………….………………………………………………………………….

9. Applying Critical Seals and Stack Gaskets……………………………………...……………………………………………………………………….

10. Setting Typical intermediate Units….......................................................................………………………………………………………………….

11. Setting Typical Head Condition Units………………………………………………….………………………………………………………………….

12. Setting Typical 90 Degree Corner Units……………………………………………….………………………………………………………………….

13. Appling Typical Perimeter Seals………………………………………………………..………………………………………………………………….

14. Deglaze / Re-glaze Procedures - Captured System................................................………………………………………………………………….

15. Deglaze / Re-glaze Procedures - SSG System…….................................................………………………………………………………………….

3 - 4

5 - 11

12 - 18

19 - 22

23 - 24

25 - 27

28 - 30

31 - 32

33

34 - 35

36

37

38

39 - 40

41 - 43

Minimizing Condensation

Note: Please reference EFCO's "Understanding Condensation" brochure which can be obtained through your EFCO representative.

Condensation will form on any surface when unfavorable conditions (interior temperature and relative humidity and exterior temperature) are present. When the formation of exces-

sive condensation is a concern, it is highly recommended that a design professional is utilized to perform an analysis of the shop drawings to recommend the best possible installation meth-
ods. Please contact your EFCO representative for information on EFCO's Thermal Analysis Services.

Many current installation practices lead to an increase in the possibility of the formation of condensation. Though not all inclusive, the list of examples below illustrates conditions

under which condensation is likely to occur:

1.

Bridging system thermal break with non-thermally broken metal flashing or lintels that are exposed to the exterior

2.

System exposure to cold air cavities

3.

Interior relative humidity levels not maintained at recommended levels, see EFCO’s “Understanding Condensation” brochure

4.

Inadequate separation between system and surrounding condition at perimeter

5.

Product combinations during the shop drawing stage that result in bridging thermal breaks

of one or all products involved.

Note: Assembly Instructions ( Y807 ) are provided as a supplement, and should be used in conjunction with the approved shop drawings.

Series 8750XD Unitized Curtain Wall Installation Instructions

EFCO 2012

Page 2
