EFCO CORPORATION 3/5/2014 PART NO. YW40 Page 2 of 2
Window Installation Instructions - Sliding Window Installation Section -
3.
Remove anti-rack / anti-takeout filler (LB24) over the sash by opening the sash all the way. Slide
the LB24 away from the jamb just far enough to get your finger between it and the jamb. Pull
down on the filler with finger and remove.
4.
Remove sash by centering it on the frame then lifting it up into the head and pulling the bottom of
the sash out.
5.
Reinstall by reversing procedure.
Completely read the General Installation Instructions and all other sections which pertain to
your project before starting work. These recommendations are for general erection
procedures only. For actual job conditions, see the details on the shop drawings. For
perimeter anchor types and spacing, refer to the approved shop drawings or consult the
project design professional.
Interior View
LB24
Interior View
Exterior Interior
