E A R L Y S T Y L E D E C K I N S T A L L A T I O N
Early Style Deck Installation
Version 4 Above Ground Model 224 Automotive Dynamometer Installation Guide
B-5
8 Secure the deck to each deck brace using two 3/8 x 1-inch bolts and two 3/8-inch
lock washers each. Make sure to use one 3/8-inch flat washer and one 3/8-inch nut
on the inside of each outer deck brace.
9 Tighten all deck brace hardware.
Figure B-4: Securing the Deck
deck
lock washer
bolt
deck brace
