Model 200iP/250iP Motorcycle Pit Dynamometer Installation Guide
C H A P T E R 3
Extended Carriage
3-18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EXTENDED CARRIAGE
The extended carriage option increases the maximum wheel base (measured from the
front of the front wheel to the center of the rear wheel) from 84 inches to 101 inches
for testing raked cruisers and drag bikes.
The extended carriage comes with a 58-inch cable carrier, instead of the standard
40-inch cable carrier. For cable routing instructions refer to “Routing the Power
Carriage and Wheel Clamp Cables” on page 2-28.
The tire carriage is fastened to the bottom of the crate next to the dyno. Refer to page
2-2 for instructions on removing the tire carriage from the crate.
P ARTS L IST
The following table lists all of the parts included in the Extended Carriage Assembly
(P/N 71323005). Check your kit against the parts listed to make sure you have
received all of the parts. If any part is missing, contact Dynojet Technical Support.
part number description quantity
150-300 Power Carriage Option, M/C Dyno 1
21224104 Carriage Clamp, M/C3 3
DM150-016-007 M/C Carriage, Right Screw Support 1
DM150-019-004 M/C Dyno Carriage Ratchet 1
DM150-019-012 Bolt, 3/8-16 x 1", Hexagonal 4
DM150-053 Bolt, 5/16 x 1" 8
21224105 Carriage Clamp Spacer, M/C3 3
21224106 Nut Driver Spacer, M/C3 1
21224114 Carriage Easy Removal Plate 1
21229107 Plate, Extended M/C Pit Carriage 1
32822100 Snap Ring, 5/8" External 1
36561045 Screw, 1/4-20 x 5/8", Pan head, Torx 4
36561670 Bolt, 1/4-20 x 1", Hexagonal 2
36580434 Bolt, 3/8-16 x 1/2", Button-head-Flange, Allan 8
36581270 Bolt, 3/8-16 x 3/4", w/tlok 1
36912100 Washer, 1/4", Splitlock, Steel 2
36932100 Washer, 3/8", Splitlock, Steel 1
37513200 Anchor, Redhead, 3/8" 4
37932100 Ratchet Strap, 2" x 3’, Black 1
61124871 Extended Carriage Trough Assembly, M/C3 1
61324102 Nut Driver Assembly, M/C3 1
61324502 Tire Stop Assembly, M/C 3 1
63310901 Tirelock Assembly with Stickers, M/C3 1
DM150-002-004 5/16" Lockwashers 8
DM150-002-007 Washer, 5/16", Flat 4
DM150-011-004 Nut, 3/8-16, Hexagonal 1
DM150-016-004 M/C Dyno Carriage Screw Bearing 1
DM150-016-005 M/D Dyno Carriage Screw 1
