Model 200iP/250iP Motorcycle Pit Dynamometer Installation Guide
2-1
C
H A P T E R
2
I
NSTALLATION
This chapter will walk you through unpacking and installing the dynamometer. To
ensure safety and accuracy in the procedures, perform the procedures as they are
described.
This chapter is divided into the following categories:
• Unpacking and Installing the Dyno, page 2-2
• Eddy Current Brake, page 2-6
• Pickup Card, page 2-12
• Carriage Plate and Tire Carriage, page 2-13
• Blower Mounts, Support Arm, and Junction Box, page 2-16
• Routing Cables, page 2-19
• Final Adjustments and Tests, page 2-37
• Pit Covers, page 2-39
• Junction Box Cover, Cable Cover, and End Cap, page 2-44
• Zip Tube, page 2-46
