13
xy calibration resolution xy calibration resolution
00 500 16 7500
01 600 17 8000
02 750 18 10000
03 800 19 12000
04 1000 20 15000
05 1200 21 20000
06 1500 22 25000
07 2000 23 30000
08 2400 24 35000
09 2500 25 40000
10 3000 26 50000
11 3500 27 60000
12 4000 28 70000
13 5000 29 75000
14 6000 30 80000
15 7000 31 100000
5.8) P8.x: calibration division
x = 0 : 1
x = 1 : 2
x = 2 : 5
5.9) P9.x: decimal point in calibration mode
x = 0 : no decimal (x10
0
x = 1 : one decimal digit (x10
)
–1
x = 2 : two decimal digits (x10
)
–2
x = 3 : three decimal digits ( x10
)
–3
x = 4 : four decimal digits (x10
)
–4
x = 5 : no decimal point (x10
)
1
5.10) P10.x: Calibration unit
)
x = 0 : kg as calibration unit
x = 1 : lb as calibration unit
As per the setting of P8, P9 and P10, following table is listed,
Table3: Kg calibration unit:
