Your New Wide TV
Side Panel Jacks
Use the side panel jacks to connect components such as a VCR. You can connect different components
such as VCRs, Set-Top Box and o DVD player etc., because there ore two sets of video input jocks and
two sets of component video input jacks on the side panel of your TV. For more information, see
"Connections".
\ \
О
ANTENNA terminals
Two independent tables or antennas can be connected to
these terminals. Use "ANT 1 IN (CABLE)" and "ANT 2 IN (AIR)"
terminals to receive a signal from VHf/UHF antennas or your
cable system. (Refer to pages 16-18)
О VIDEO/AUDIO input jacks
Connect video/audio signals from externol sources, such os VCR
or DVD ployers. (Refer to poges 19~20 and 22}
О S-VIDEO input jacks
Connects an S-Video signal from an S-VHS VCR or DVD player.
(Refer to page 19-20)
О
VIDEO/AUDIO output jacks
Sends video/audio signals from the TV to an external source,
such as a VCR. These jacks are ovailable only in TV, Video and
S-Video modes. (Refer to роде 19)
О COMPONENT IN 1, 2 jacks (Y, P
b
, P
r
, AUDIO L/R)
Use these jacks to connect the component video/audio signols
from a DVD player or a Set-Top Box. (Refer to pages 21 -22)
О
SERVICE
This jack is for service only.
О DIGITAL AUDIO OUT (OPTICAL) jack
Connect to a Digital Audio Component. (Refer to page 24)
О
DVI (Digital Video Interface) AUDIO input jacks
Connect to the DVI audio output jacks of a device with DVI
output. (Refer to page 23)
O PC VIDEO Input jack
Connect to the video output jack on your PC.
(Referto page 106)
(D PC AUDIO Input jack
Connect to the audio output jack on your PC.
(Referto page 106)
You can connect a USB mass storage device to view photo files (JPEG) end play audio files (MP3). 0 HDMI (High Definition Multimedia Interface)/ DVI Input jack (HDMI 1/DVI IN) Connect to the HDMI jock of o device with HOMI output. This input can also be used as a DVI connection with separate analog audio inputs. An optional HDMI/DVI cable will he necessory to make this connection. When using the optional you to receive left and right oudio from your DVI device. (Not 0 HDMI (High Definition Multimedia Interface) Input jack (HDMI IN 2) Connect to the HDMI jock of o device with HOMI output. 0 POWER IN Connect the supplied power cord. English - 1 2
HDMI/DVI adopter, the DVI analog audio inputs on your TV ollow
compatible with PC) (Refer to page 23)
(Referto page 23}
