Tomei Powered ARMS M8265 Single Scroll - Manual (Page 12)

CAUTION
■ This manual is for the instructions on the removal and re-installation of this turbo kit.
You will need to have the official service manual (from Fuji Heavy Industries) for your car for additional
reference on the disassembly and reassembly of other related parts.
■ This product is designed to be used for off road competition purposes. This product may not be road legal in your
country so please check with your local authorities prior to use on general public roads.
■ This product will increase your engines power output so it is necessary to address and upgrade your suspension
and brakes to suit the increased power for added safety.
■ This product was specifically designed for the vehicle application as stated above. This is not designed and
may not be suitable for other cars/engines other than stated in this manual. If this product/kit is installed
on any other vehicles/engines it may damage this product and /or the engine /vehicle that it is fitted to.
■ This installation manual simply explains the removal and installation of the turbo unit as well as the air pipe(s),
heat shield and the coolant as well. Please read this manual carefully in advance to prepare all the necessary
tools required for the job.
■ This product is to be fitted by an experienced professional in a fully equipped workshop.
■ Protective equipment may be required for the installation process so please ensure there is the appropriate
safety and 1st aid equipment readily available for the installation.
■ It is best to work on the car when the engine is cold as it will prevent possible burns and or injuries when
the engine is hot.
■ When removing and re-fitting the parts please perform the job with care. Do not use excessive force on the
bolts and parts so as not to cause any damages to the parts and/or related parts.
■ Please tighten each bolt with a torque wrench.
This will prevent any possible damages to the bolt and also ensure that it won’t come undone.
■ Prior to testing the car please check for adequate levels of coolant and any signs of leakage.
If there are signs of lack of coolant, leaks and/or rapid rising of temperature stop the car immediately so as
not to risk engine damage.
12
Have a boost gauge fitted to your car (if not already) to monitor the turbo via the boost levels to ensure
that it is operating as normal.
REQUIRED TOOLS
・ GENERAL ENGINE MAINTENANCE TOOLS ・TORQUE WRENCH
・WORKSHOP SERVICE MANUAL
