Jumpers and Connectors
175
Item
Connector
Description
1
SLOT4_PCIE_G2_X8
slot 4 PCIe - x8 link expansion slot
2
SLOT3_PCIE_G2_X8
slot 3 PCIe - x8 link expansion slot
3
AMEA CONN
iDRAC6 Enterprise card connector
4
PWRD_EN
NVRAM_CLR
Password enable jumper
NVRAM clear jumper
5
MASER CONN
iDRAC6 Express card connector
6
Center PCIE_G2_X8
Expansion-card riser 1 connector
7
BATTERY
Battery socket
8
SATA
SATA power connector
9
FAN6
System cooling fan 6 connector
10
FAN5
System cooling fan 5 connector
11
CPU1
Processor 1 socket
12
A1
Memory module slot A1(white release lever)
A5
Memory module slot A5
A2
Memory module slot A2 (white release lever)
A6
Memory module slot A6
A3
Memory module slot A3 (white release lever)
A7
Memory module slot A7
A4
Memory module slot A4 (white release lever)
A8
Memory module slot A8
13
B1
Memory module slot B1 (white release lever)
B5
Memory module slot B5
B2
Memory module slot B2 (white release lever)
B6
Memory module slot B6
B3
Memory module slot B3 (white release lever)
B7
Memory module slot B7
B4
Memory module slot B4 (white release lever)
