System Board
Removing the System Board
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
CAUTION:
If you are using the Trusted Program Module (TPM) with an encryption
key, you may be prompted to create a recovery key during program or system
setup. Be sure to create and safely store this recovery key. If you replace this
system board, you must supply the recovery key when you restart your system or
program before you can access the encrypted data on your hard drives.
1 Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet.
2 If applicable, remove the front bezel. See "Removing the Front Bezel" on
3 Open the system. See "Opening the System" on page 76.
4 Remove the cooling shroud. See "Removing the Cooling Shroud" on
5 Remove any expansion card. See "Removing an Expansion Card" on
6 Remove the heat sink and the processor. See "Removing a Processor" on
WARNING:
The heat sink can get hot during operation. To avoid burns, ensure
that the system has sufficient time to cool before removing the system board.
7 Remove the system battery. See "Replacing the System Battery" on
8 If installed, remove the iDRAC6 Enterprise card. See "Removing an
iDRAC6 Enterprise Card" on page 111.
9 If installed, remove the iDRAC6 Express card. See "Removing an iDRAC6
10 Disconnect all cables from the system board.
