Installing System Components 123
4 To remove the battery, push the metal tab away from the battery until the
battery pops out. See Figure 3-20.
5 To install the new system battery, hold the battery with the “+” facing up,
and aligned to the metal tab on the socket.
Figure 3-20. Replacing the System Battery
6 Press the battery straight down into the socket until it snaps into place.
7 Close the system. See "Closing the System" on page 77.
8 Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
9 Enter the System Setup program to confirm that the battery is operating
properly. See "Entering the System Setup Program" on page 52.
10 Enter the correct time and date in the System Setup program's Time and
Date fields.
11 Exit the System Setup program.
1 positive side of battery connector 2 negative side of battery connector
3 system battery
1
2
3
