Dell Inspiron 7000 - Manual (Page 90)

Connectors
Audio
Video
14.1-Inch Display
Serial (DTE) (1) 9-pin connector; 16550-compatible, 16-byte buffer
Parallel (1) 25-hole connector; normal (unidirectional), bidirectional, EPP 1.9 or
ECP
Monitor (1) 15-hole connector
PS/2 keyboard/mouse (1) 6-pin mini-DIN connector
Infrared 1 IrDA 1.1 port
Expansion connector 240 pins
TV-out (1) 7-pin S-video
Audio microphone, headphones/speakers, and line-out jacks
USB (1) 4-pin connector
RJ11 1 RJ11 modem port (optional)
Audio type Sound Blaster Pro-compatible voice and music functions, HRTF 3D
positional audio, hardware wavetable
Audio controller ESS Technology Maestro-2
Conversion 20 bit (stereo analog-to-digital and digital-to-analog)
Hardware wavetable synthesizer 64-voice
Interfaces:
Internal PCI bus, integrated stereo speakers and microphone
External microphone (minijack, mono), headphones, line-in
Internal speaker amplifier 1.0-W stereo (0.5 W per speaker)
External microphone input voltage range 280 mV peak-to-peak
Line/audio input voltage range 2.8 V peak-to-peak
Controls volume can be controlled through thumb wheel, software application
menus, and keyboard
Video type AGP 2X with sideband signals, hardware 3D accelerator, DVD motion
compensation, ImpacTV2-quality TV output
Video controller ATI RAGE Mobility - P video with AGP 2x, 4M/8M SGRAM
Video memory 4- or 8-MB 100-MHz SGRAM
LCD interface 65-MHz LVDS
TV support NTSC or PAL in S-video and composite modes
Type active-matrix color (XGA)
Dimensions (active area):
Height 54 mm (2.1 inches)
Width 318 mm (12.5 inches)
Depth 254 mm (10 inches)
Diagonal 358.1 mm (14.1 inches)
