S-Video TV-Out Connector

If the television has an S-video cable, plug it directly into the system at the S-video TV-out connector. If the television has a composite cable, complete the following
steps:

1. Connect the cable that came with your system to the S-video TV-out connector.
2. Connect the other end of the cable to the television's composite cable.

1

EXK_MSDATA

I/O

External keyboard/keypad/mouse data

2

NC

N/A

No connection

3

GND

N/A

Signal ground

4

EXK_MSPWR

N/A

External keyboard/keypad/mouse supply voltage

5

EXK_MSCLK

I/O

External keyboard/keypad/mouse clock

6

NC

N/A

No connection

Shell

N/A

N/A

Chassis ground
