Dell POWEREDGE R610 User Manual
Dell Computers
Table of contents
Document Outline
- Dell™ PowerEdge™ R610 Systems Hardware Owner’s Manual
- Notes, Cautions, and Warnings
- Contents
- About Your System
- Accessing System Features During Startup
- Front-Panel Features and Indicators
- LCD Panel Features
- Hard-Drive Indicator Patterns for RAID
- Back-Panel Features and Indicators
- Power Indicator Codes
- NIC Indicator Codes
- LCD Status Messages
- System Messages
- Warning Messages
- Diagnostics Messages
- Alert Messages
- Other Information You May Need
- Using the System Setup Program and UEFI Boot Manager
- Choosing the System Boot Mode
- Entering the System Setup Program
- System Setup Options
- Entering the UEFI Boot Manager
- System and Setup Password Features
- Using the System Password
- Using the Setup Password
- iDRAC Configuration Utility
- Installing System Components
- Recommended Tools
- Inside the System
- Removing and Replacing the Optional Front Bezel
- Information Tag
- Removing the Information Tag
- 1 Remove the front bezel. See "Removing and Replacing the Optional Front Bezel."
- 2 Pull the information tag out of its slot in the chassis until it is in the locked position. See Figure 1-1 in "About Your System" for the location of the information tag slot.
- 3 Pull the tag to the right until it disengages from the slot in the chassis to release the left portion of the tag.
- 4 Pull the tag to the left until it disengages from the slot in the chassis to release the right portion of the tag.
- 5 Remove the tag.
- Replacing the Information Tag
- 1 Remove the front bezel. See "Removing and Replacing the Optional Front Bezel."
- 2 Locate the information tag slot on the front of the system chassis. See Figure 1-1 in "About Your System" for the location of the information tag slot.
- 3 Holding the information tag horizontally, slide it into the information tag slot until it locks into place.
- Removing the Information Tag
- Opening and Closing the System
- Opening the System
- 1 Turn off the system and attached peripherals, and disconnect the system from the electrical outlet and peripherals.
- 2 Rotate the latch release lock counter clockwise to the unlocked position. See Figure 3-3.
- 3 Lift up on the latch on top of the system and slide the cover back. See Figure 3-3.
- 4 Grasp the cover on both sides and carefully lift the cover away from the system.
- Figure 3-3. Removing and Replacing the System Cover
- Closing the System
- 1 Lift up the latch on the cover.
- 2 Place the cover onto the chassis and offset it slightly towards the back of the system, so that the two hooks on the back edge of the cover fit over the corresponding tabs on the back edge of the chassis. See Figure 3-3.
- 3 Slide the cover towards the front of the chassis and close the latch.
- 4 Rotate the latch release lock in a clockwise direction to secure the cover.
- Opening the System
- Hard Drives
- Removing a Drive Blank
- Installing a Hard-Drive Blank
- Removing a Hot-Swap Hard Drive
- 1 Remove the front bezel. See "Removing the Front Bezel."
- 2 Using the RAID management software, prepare the drive for removal. Wait until the hard-drive indicators on the drive carrier s...
- 3 Press the release button and open the drive carrier release handle to release the drive. See Figure 3-5.
- 4 Slide the hard drive out of the drive bay.
- 5 Insert a drive blank in the vacated drive bay. See "Installing a Drive Blank."
- Installing a Hot-Swap Hard Drive
- Removing a Hard Drive From a Hard-Drive Carrier
- Installing a Hard Drive Into a Hard-Drive Carrier
- 1 Insert the hard drive into the hard-drive carrier with the connector end of the drive at the back. See Figure 3-6.
- 2 Align the holes on the hard drive with the back set of holes on the hard drive carrier.
- 3 Attach the four screws to secure the hard drive to the hard-drive carrier.
- Figure 3-6. Installing a Hard Drive Into a Drive Carrier
- Power Supplies
- Removing a Power Supply
- Installing a Power Supply
- 1 On a system with redundant power supplies, verify that both power supplies are the same type and have the same maximum output power.
- 2 Slide the new power supply into the chassis until the power supply is fully seated and the release latch snaps into place. See Figure 3-7.
- 3 Connect the power cable to the power supply and plug the cable into a power outlet.
- Removing the Power Supply Blank
- Installing the Power Supply Blank
- Expansion Cards
- Expansion Card Installation Guidelines
- Installing an Expansion Card
- 1 Unpack the expansion card and prepare it for installation.
- 2 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 3 Open the system. See "Opening the System."
- 4 Open the expansion-card latch and remove the filler bracket. See Figure 3-8.
- 5 Install the expansion card:
- a Holding the card by its edges, position the card so that the card-edge connector aligns with the expansion-card connector on the expansion- card riser.
- b Insert the card-edge connector firmly into the expansion-card connector until the card is fully seated.
- c Close the expansion-card latch. See Figure 3-8.
- Figure 3-8. Installing or Removing an Expansion Card
- Removing an Expansion Card
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Disconnect all cables from the card.
- 4 Remove the expansion card:
- 5 If you are removing the card permanently, install a metal filler bracket over the empty expansion slot opening and close the expansion-card latch.
- 6 Close the system. See "Closing the System."
- Expansion-Card Risers
- Removing an Expansion-Card Riser
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 If an expansion card is installed in the expansion slot, remove the card now. See "Removing an Expansion Card."
- 4 If you are removing the riser 1, remove the integrated storage controller card. See "Removing the Integrated Storage Controller Card."
- 5 To remove the expansion-card riser, press the retention latch, then lift the expansion-card riser from the chassis. See Figure 3-9.
- Figure 3-9. Installing or Removing an Expansion-Card Riser
- Replacing an Expansion-Card Riser
- 1 To install an expansion-card riser, align the board with the riser guide posts on the system board. See Figure 3-9.
- 2 Lower the expansion-card riser into place until the expansion-card riser connector is fully seated.
- 3 If applicable, reinstall the expansion card. See "Installing an Expansion Card."
- 4 If you are installing expansion-card riser 1, reinstall the integrated storage controller card. See "Installing the Integrated Storage Controller Card."
- 5 Close the system. See "Closing the System."
- 6 Reconnect the system and peripherals to their power sources.
- Removing an Expansion-Card Riser
- Internal SD Module
- Installing the Internal SD Module
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Position the internal SD module tray so the tabs on the underside of the tray fit into the corresponding hooks on the chassis (item 3 in Figure 3-10), then lower the opposite edge of the card into place. See Figure 3-10.
- Figure 3-10. Installing the Internal SD Module
- Removing the Internal SD Module Card
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Disconnect the internal SD module cable from the module. See Figure 3-10.
- 4 Lift upwards on the latch securing the internal SD module card tray to the chassis, then lift the tray out of the chassis. See Figure 3-10.
- Installing the Internal SD Module
- Internal SD Flash Card
- Installing an Internal SD Flash Card
- 1 Turn off the system, including any attached peripherals, and disconnect the system from its electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Locate the SD card connector on the internal SD module (see Figure 3-10).
- 4 With the label side facing up, insert the contact-pin end of the SD card into the card slot on the module. See Figure 3-10.
- 5 Press the card into the card slot to lock it into place.
- 6 Close the system. See "Closing the System."
- 7 Reconnect the system to power and restart the system.
- Removing an Internal SD Flash Card
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Locate the SD card slot on the internal SD module and press inward on the card to release it from the slot and remove the card.
- 4 Close the system. See "Closing the System."
- 5 Reconnect the system to power and restart the system.
- Installing an Internal SD Flash Card
- Internal USB Memory Key
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Locate the USB connector on the control panel board. See Figure 3-11.
- 4 Insert the USB memory key into the USB connector.
- 5 Close the system. See "Closing the System."
- 6 Reconnect the system to power and restart the system.
- Figure 3-11. Removing or Installing the Internal USB Memory Key
- Internal USB Cable
- Removing the Internal USB Cable
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Remove the fan bracket. See "Removing the Fan Assembly."
- 4 Remove the USB cable from the connector on the control panel.
- 5 Remove the USB cable from the cable routing guides on the inside of the chassis. If necessary remove any other cables from the cable routing guides.
- 6 Remove the USB cable from the connector on the system board.
- Installing the Internal USB Cable
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Remove the fan bracket. See "Removing the Fan Assembly."
- 4 Connect the USB cable to the connector on the control panel.
- 5 Route the cable through the cable routing guides on the inside of the chassis.
- 6 Connect the USB cable to the connector on the system board.
- 7 Replace the fan bracket. See "Replacing the Fan Assembly."
- 8 Close the system. See "Closing the System."
- 9 Reconnect the system and peripherals to their power sources, and turn them on.
- Removing the Internal USB Cable
- VFlash Media
- Installing a VFlash Media Card
- 1 Locate the VFlash media slot at the back corner of the system. See "Back- Panel Features and Indicators" for the location of the media slot.
- 2 With the label side facing up, insert the contact-pin end of the SD card into the card slot on the module.
- 3 Press inward on the card to lock it into the slot.
- Removing a VFlash Media Card
- Installing a VFlash Media Card
- iDRAC6 Enterprise Card (Optional)
- Installing an iDRAC6 Enterprise Card
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Remove the plastic filler plug from the system back panel.
- 4 If installed, remove the expansion card from expansion-card riser 1. See "Removing an Expansion Card."
- 5 Install the iDRAC6 Enterprise card:
- Figure 3-12. Installing or Removing an iDRAC6 Enterprise Card
- Removing an iDRAC6 Enterprise Card
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Disconnect the Ethernet cable from the iDRAC6 Enterprise Card connector on the system back panel. See Figure 1-4.
- 3 Open the system. See "Opening the System."
- 4 Remove the VFlash media from the iDRAC6 Enterprise Card. See"Removing a VFlash Media Card."
- 5 If installed, remove the expansion card from expansion-card riser 2. See "Removing an Expansion Card."
- 6 Remove the iDRAC6 Enterprise card:
- 7 Reinstall the expansion card. See "Installing an Expansion Card."
- 8 Close the system. See "Closing the System."
- 9 Reconnect the system and peripherals to their power sources, and turn them on.
- Installing an iDRAC6 Enterprise Card
- NIC Hardware Key
- 1 Turn off the system, including any attached peripherals, and disconnect the system from its electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Locate the ISCSI_KEY connector on the system board. See Figure 6-1.
- 4 Insert the NIC hardware key into the connector. See Figure 3-13.
- Figure 3-13. Installing a NIC Hardware Key
- Cooling Fans
- Removing a Cooling Fan
- 1 Turn off the system, including any attached peripherals, and disconnect the system from its electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Disconnect the fan’s power cable from the system board. See Figure 3-14.
- 4 Remove the faulty fan by grasping the two blue touch points on the fan and sliding the fan from the fan assembly. See Figure 3-14.
- Figure 3-14. Removing and Replacing a Fan
- Replacing a Cooling Fan
- Removing the Fan Assembly
- 1 Turn off the system, including any attached peripherals, and disconnect the system from its electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Disconnect each fan’s power cable from the system board. See Figure 3-14.
- 4 Lift the two latches on the top of the fan assembly, then lift the fan assembly from the chassis.
- Figure 3-15. Removing and Replacing the Fan Assembly
- Replacing the Fan Assembly
- Removing the Plastic Fan Guide
- 1 Turn off the system, including any attached peripherals, and disconnect the system from its electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 If necessary, remove the fan bracket. See "Removing the Fan Assembly" and place the fan assembly on a flat surface.
- 4 Remove the fan guide by toggling the two small pegs on the plastic guide out of the two holes in the fan assembly. For the location of the fan guide and latches see Figure 3-15.
- Replacing the Plastic Fan Guide
- 1 Turn off the system, including any attached peripherals, and disconnect the system from its electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 If necessary, remove the fan bracket. See "Removing the Fan Assembly" and place the fan assembly on a flat surface.
- 4 Replace the guide by aligning the 2 small pegs on the guide with the two holes in the fan bracket. See Figure 3-15.
- 5 Replace the fan bracket. See "Replacing the Fan Assembly."
- 6 Close the system. See "Closing the System."
- 7 Reconnect the system and peripherals to their power sources, and turn them on.
- Removing a Cooling Fan
- Optical Drive
- Removing an Optical Drive
- 1 Remove the bezel. See "Removing and Replacing the Optional Front Bezel."
- 2 Turn off the system, including any attached peripherals, and disconnect the system from its electrical outlet.
- 3 Open the system. See "Opening the System."
- 4 Disconnect the cable connector labeled OPTICAL from the back of the drive.
- 5 To remove the drive carrier, press the release latch, then slide the carrier out of the chassis. See Figure 3-16.
- 6 Close the system. See "Closing the System."
- 7 Replace the front bezel, if applicable. See "Removing and Replacing the Optional Front Bezel."
- Figure 3-16. Removing the Optical Drive
- Installing an Optical Drive
- 1 Remove the bezel. See "Removing and Replacing the Optional Front Bezel."
- 2 Turn off the system, including any attached peripherals, and disconnect the system from its electrical outlet.
- 3 Open the system. See "Opening the System."
- 4 To remove the optical drive blank, press down on the blue release tab at the back of the blank and push the blank out of the system.
- 5 Align the optical drive with its opening in the front panel.
- 6 Slide in the optical drive until the latch snaps into place.
- 7 Connect the cable connector labeled OPTICAL to the back of the drive.
- 8 If not already done, connect the power cable to DVD_PWR and the interface cable to SATA_A on the system board. See Figure 6-1.
- 9 Replace the front bezel, if applicable. See "Removing and Replacing the Optional Front Bezel."
- 10 Reconnect the system and peripherals to their electrical outlets.
- Removing an Optical Drive
- Integrated Storage Controller Card
- Removing the Integrated Storage Controller Card
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Disconnect the data cables from the controller card. See Figure 3-17.
- 4 If you are removing a battery-cached PERC controller, disconnect the RAID battery cable from the card.
- 5 Remove the card from the storage controller card slot:
- a Grasp the expansion card by its edges, bend outward on both card- edge guides, and carefully remove the card from the expansion-card connector.
- b With the blue card-edge guides still bent outwards, lift the side of the controller that is adjacent to the blue guide, and then remove the controller towards the front of the chassis.
- Installing the Integrated Storage Controller Card
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Install the controller card in the expansion slot on riser 1 labeled INT_STORAGE.
- 4 Connect the card to the SAS backplane:
- a Connect the SAS data cable connector labelled "SAS_0" to the white SAS_0 connector on the card, and the connector labelled "SAS_1" to the black SAS_1 connector on the card. See Figure 3-17.
- b Route the SAS data cable through the channel on the inner side of the chassis.
- c Unlatch the fan assembly and lift it far enough out of the chassis to route the SAS cable along the inside of the chassis, und...
- d Attach the connector labeled "SAS A" to connector SAS A on the backplane, and attach the connector labeled "SAS B" to connector SAS B on the backplane. See Figure 3-17.
- Figure 3-17. Installing the Integrated Storage Controller Card
- Removing the Integrated Storage Controller Card
- RAID Battery
- Removing a RAID Battery
- Installing a RAID Battery
- Removing the PERC 6/I Battery Cable
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Disconnect the battery cable from the PERC controller. See Figure 3-17 for the battery connection location.
- 4 Remove the battery cable from the cable clip on the system board nearest PSU #2.
- 5 Follow the cable along the inside wall of the chassis.
- 6 Remove the fan bracket. See "Removing the Fan Assembly" on page 106.
- 7 Remove the fan cable from the plastic cable routing guide. It might be necessary to remove other cables from the routing guide.
- 8 Disconnect the battery cable from the RAID battery.
- Installing the PERC 6/I Battery Cable
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Remove the fan bracket. See "Removing the Fan Assembly" on page 106.
- 4 Connect the battery cable to the RAID battery.
- 5 Route the battery cable on the inside of the chassis wall through the plastic cable routing guide. If any other cables were removed from the routing guide, route those cables through the routing guide as well.
- 6 Route the cable on the inside of the chassis wall, place the cable in the cable clip nearest PSU #2.
- 7 Route the cable to the PERC controller and connect it to the battery connector on the PERC controller.
- 8 Replace the fan bracket. See "Replacing the Fan Assembly" on page 107.
- 9 Close the system. See "Closing the System."
- 10 Reconnect the system to its electrical outlet and turn the system on, including any attached peripherals.
- System Memory
- General Memory Module Installation Guidelines
- Mode-Specific Guidelines
- Installing Memory Modules
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Locate the memory module sockets. See Figure 6-1.
- 4 Press the ejectors on the memory module socket down and out, as shown in Figure 3-18, to allow the memory module to be inserted into the socket.
- 5 Handle each memory module only on either card edge, making sure not to touch the middle of the memory module.
- Figure 3-18. Installing and Removing a Memory Module
- 6 Align the memory module's edge connector with the alignment key of the memory module socket, and insert the memory module in the socket.
- 7 Press down on the memory module with your thumbs to lock the memory module into the socket.
- 8 Repeat step 4 through step 7 of this procedure to install the remaining memory modules. See Table 3-3.
- 9 Close the system. See "Closing the System."
- 10 Start up the system, press
to enter the System Setup program, and check the System Memory setting on the main System Setup screen. - 11 If the value is incorrect, one or more of the memory modules may not be installed properly. Repeat step 2 through step 10 of this procedure, checking to ensure that the memory modules are firmly seated in their sockets.
- 12 Run the system memory test in the system diagnostics. See "Running the System Diagnostics."
- Removing Memory Modules
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Locate the memory module sockets. See Figure 6-1.
- 4 Press down and out on the ejectors on each end of the socket until the memory module pops out of the socket. See Figure 3-18.
- 5 Close the system. See "Closing the System."
- Processors
- Removing a Processor
- 1 Prior to upgrading your system, download and install the latest system BIOS version from support.dell.com. Follow the instructions included in the file download to install the update on your system.
- 2 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 3 Open the system. See "Opening the System."
- 4 Open one of the heat-sink retention latches by pressing the end of the latch, moving it laterally, and lifting the latch upwards. See Figure 3-19.
- Figure 3-19. Installing and Removing the Heat Sink
- 5 Wait 30 seconds for the heat sink to loosen from the processor.
- 6 Open the other heat-sink retention latch.
- 7 Gently lift the heat sink off of the processor and set the heat sink aside upside down (thermal grease side facing up).
- 8 Position your thumb firmly over the processor socket-release lever and release the lever from the locked position. Rotate the lever 90 degrees upward until the processor is released from the socket. See Figure 3-20.
- 9 Rotate the processor shield upward and out of the way. See Figure 3-20.
- 10 Lift the processor out of the socket and leave the release lever up so that the socket is ready for the new processor.
- Figure 3-20. Installing and Removing a Processor
- Installing a Processor
- 1 If you are upgrading your processors, prior to upgrading your system, download and install the latest system BIOS version from support.dell.com. Follow the instructions included in the file download to install the update on your system.
- 2 If you are adding a second processor for the first time, remove the heatsink blank and the processor blank from the vacant processor socket. Removing the blanks is similar to removing a processor. See "Removing a Processor."
- 3 Unpack the processor if it has not been used previously.
- 4 Align the processor with the socket keys on the ZIF socket. See Figure 3-20.
- 5 Install the processor in the socket.
- 6 Install the heat sink.
- a Using a clean lint-free cloth, remove any thermal grease from the heat sink.
- b Open the grease packet included with the processor kit and apply a small amount (approximately 1.5 cm (.6 in) in diameter of thermal grease to the center of the top of the new processor.
- c Place the heat sink on the processor. See Figure 3-20.
- d Close the two heat-sink retention latches. See Figure 3-20.
- 7 Close the system. See "Closing the System."
- 8 Press
to enter the System Setup program, and check that the processor information matches the new system configuration. See "Entering the System Setup Program." - 9 Run the system diagnostics to verify that the new processor operates correctly.
- Removing a Processor
- System Battery
- Replacing the System Battery
- 1 Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- Figure 3-21. Replacing the System Battery
- 3 Locate the battery socket. See Figure 6-1.
- 4 Remove the system battery.
- 5 Install the new system battery.
- 6 Close the system. See "Closing the System."
- 7 Reconnect the system to the electrical outlet and turn the system on, including any attached peripherals.
- 8 Enter the System Setup program to confirm that the battery is operating properly. See "Entering the System Setup Program."
- 9 Enter the correct time and date in the System Setup program's Time and Date fields, and configure the other settings for your system.
- 10 Exit the System Setup program.
- Replacing the System Battery
- Control Panel Assembly
- 11 Turn off the system and attached peripherals, and disconnect the system from the electrical outlet and peripherals.
- 12 Open the system. See "Opening the System."
- 13 Disconnect the display module cable from the control panel board. See Figure 3-22.
- 14 Using a knife or a small flat-blade screwdriver, insert the blade beneath the front panel of the display and slide the blade across the bottom to lift the panel outward. See Figure 3-22.
- 15 Bend the panel upward to allow access to the mounting screws.
- Figure 3-22. Control Panel Removal
- Installing the Control Panel Display Module
- 1 Insert the display module into the chassis cutout and secure with the two Torx screws. See Figure 3-22.
- 2 Attach the replacement panel to the front of the display module.
- 3 Connect the display module cable to the control panel board.
- 4 Close the system. See "Closing the System."
- 5 Reconnect the system to the power source and turn on the system and attached peripherals.
- Removing the Control Panel Board
- 1 Turn off the system and attached peripherals and disconnect the system from the electrical outlet and peripherals.
- 2 Open the system. See "Opening the System."
- 3 Disconnect the display module cable from the control panel board. See Figure 3-22.
- 4 Disconnect the control panel cable and USB cable from the control panel board. See Figure 3-22.
- 5 If applicable, disconnect the Internal SD Module cable and remove the USB key from the control panel module.
- 6 Using a T8 Torx driver, remove the screw on the front panel located beneath the left USB connector. See Figure 3-22.
- 7 Using a T10 Torx driver, remove the three screws that secure the control panel board to the system chassis and remove the board.
- Installing the Control Panel Board
- 1 Install the front panel screw in the screw hole located beneath the left USB connector. See Figure 3-22.
- 2 Install the control panel board in the system chassis and secure with the three Torx screws. See Figure 3-22.
- 3 Connect the display module cable to the control panel board.
- 4 Connect the control panel cable and USB cable to the control panel board.
- 5 If applicable, reconnect the Internal SD Module cable to the control panel board, and install the USB key.
- 6 Close the system. See "Closing the System."
- 7 Reconnect the system to the power source and turn on the system and attached peripherals.
- SAS Backplane
- Removing the SAS Backplane
- 1 If applicable, remove the bezel. See "Removing the Front Bezel."
- 2 Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
- 3 Open the system. See "Opening the System."
- 4 Remove all hard drives. See "Removing a Hot-Swap Hard Drive."
- 5 Disconnect the power cable from the end of the SAS backplane.
- 6 Disconnect the SAS data cables from the backplane.
- 7 Remove the SAS backplane from the system:
- a While pulling the two blue latches towards the front of the system, slide the backplane upward. See Figure 3-23.
- b When the backplane cannot slide upward any farther, pull the backplane toward the back of the system to remove it from the retention hooks.
- c Lift the board out of the system, being careful to avoid damaging components on the face of the board.
- d Place the SAS backplane face down on a work surface.
- Figure 3-23. Removing and Installing a SAS Backplane
- Installing a SAS Backplane
- 1 Install the SAS backplane:
- a Lower the backplane into the system, being careful to avoid damaging components on the face of the board.
- b Align the slots in the backplane with the retention hooks on the back of the drive bays, then move the backplane forward until the retention hooks fit through the slots in the backplane. See Figure 3-23.
- c Slide the backplane downward until the two blue retention latches snap into place.
- 2 Connect the SAS data and power cables to the SAS backplane.
- 3 If you removed the fan assembly to improve access to the SAS backplane, replace the fan assembly now. See "Replacing a Cooling Fan."
- 4 Install the hard drives in their original locations.
- 5 Close the system. See "Closing the System."
- 6 Reconnect the system to its electrical outlet and turn the system on, including any attached peripherals.
- 1 Install the SAS backplane:
- Removing the SAS Backplane
- System Board
- Removing the System Board
- 1 Turn off the system and attached peripherals, and disconnect the system from the electrical outlet.
- 2 Open the system. See "Opening the System."
- 3 Remove the power supply(s). See "Removing a Power Supply."
- 4 Remove all expansion cards and the integrated storage controller card. See "Removing an Expansion Card" and "Removing the Integrated Storage Controller Card."
- 5 Remove the two expansion-card risers. See "Removing an Expansion-Card Riser."
- 6 If installed, remove the iDRAC6 Enterprise card. See "Removing an iDRAC6 Enterprise Card."
- 7 If installed, remove the NIC hardware key from the system board. See "NIC Hardware Key."
- 8 Disconnect and remove the fan assembly. See "Cooling Fans."
- 9 Disconnect all cables from the system board.
- 10 Remove the system board assembly:
- a Pull up the spring-loaded blue retention pin located in the center of the system board, and then slide the system board assembly toward the front end of the chassis.
- b Grasp the system board assembly by the blue and black storage card guides, or the edges of the system board tray, and lift the assembly from the chassis. See Figure 3-24.
- Figure 3-24. Removing and Installing the System Board
- Installing the System Board
- 1 Unpack the new system board and remove the label placard that is inserted in the memory module socket.
- 2 Remove the labels from the placard and affix them to the system information panel on the front of the system. See Figure 1-1.
- 3 Transfer the processors and heat sinks to the new system board. See "Removing a Processor" and "Installing a Processor."
- 4 Remove the memory modules and transfer them to the same locations on the new board. See "Removing Memory Modules" and "Installing Memory Modules."
- 5 Install the new system board:
- a Holding the system board by the edges of the system board tray, lower the right side of the system board into the chassis.
- b Slowly lower the left side of the system board into the chassis.
- c Slightly lift up the front of the system board and maneuver the system board to the bottom of the chassis until it lays completely flat.
- d Ensure that all retention hooks on the bottom of the chassis are inserted into the retention slots on the system board. See Figure 3-24.
- e Push the system board toward the back of the chassis until the blue retention pin snaps into place.
- 6 Transfer the NIC hardware key. See "NIC Hardware Key."
- 7 Connect the cables in the order listed below (see Figure 6-1 for the locations of the connectors on the system board):
- 8 Replace the expansion-card risers. See "Replacing an Expansion-Card Riser."
- 9 Install all expansion cards. See "Installing an Expansion Card."
- 10 Reinstall the integrated storage controller card. See "Installing the Integrated Storage Controller Card."
- 11 If applicable, reconnect the RAID battery cable to the PERC controller card.
- 12 If applicable, reinstall the iDRAC6 Enterprise card. See "Installing an iDRAC6 Enterprise Card."
- 13 Replace the fan assembly. See "Cooling Fans."
- 14 Close the system. See "Closing the System."
- 15 Reconnect the system to its electrical outlet and turn the system on, including any attached peripherals.
- 16 Replace the bezel. See "Removing and Replacing the Optional Front Bezel."
- Removing the System Board
