www.baumer.com Operators Instruction: 11126179 00 Page 4 / 36
Operators Instruction
Dimensions
Welding connection Clamp connection Screwed connections Union nut
Short version 3A versions Standard Long version 3A versions Standard
40,5 mm 37 mm 87 mm 83 mm
G1” mounting adapters
DN 40...50 PM052-1 Variline, type N VAM053 SMS 1145 DN 38 SAM-038-1 SNF038
DN 65...150 PM052-2 SMS 1145 DN 51 SAM-051-1 SNF051
More adapters are available, e.g. with standard industrial thread. Please see data sheet for Accessories.
For tank
For tube
PM053 ISO 2852 DN38 CAM050-505 DIN 11851 DN 32 MAM050-032 MNF032
ISO 2852 DN51 CAM050-640 DIN 11851 DN 40 MAM050-040 MNF040
DIN 11851 DN 50 MAM050-050 MNF050
The two above sensors are 3A approved when mounted in one of below 3A approved G1” mounting adapters
Front view Bottom connection
Ш6,6
Ш25,5
87
128
83
37
Ш6,6
Ш25,5
4
0
,5
82
English
CombiLyz, AFI4
