SAVE THESE INSTRUCTIONS!
GRETA-W-_-L1-_
M2-IND-_
Installation Instructions for
Greta LED
904-GRETA-W-L1-04
IMPORTANT INFORMATION
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
1
© 2014 Edge Lighting. All Rights Reserved.
Disassemble the Fixture
A
SCREW HEAD
SLOT
1: Remove the Phillips screw on one end of the shade and slide
the shade off the backplate.
PHILLIPS SCREW
1
SHADE
BACKPLATE
2: Remove the LED mounting plate by loosening the six 1.5mm screws using an M3 Allen wrench.
B
2
1.5MM SCREW
LED MOUNTING
PLATE
NUT
MOUNTING
POST
BACK PLATE
C
3: Loosen and remove two nuts from the threaded posts
4: Remove the fixture back plate from the mounting plate.
3
- Use this fixture indoors only.
- This product is ETL listed for indoor dry locations.
- This product is wall mounted only.
- This product can mount to either a 4" square junction box
with round plaster ring or an octagon junction box.
- This product can be dimmed with a standard low-voltage
electronic dimmer.
- This product must be installed by a qualified electrician.
- Before beginning any electrical work, ensure that
power to the junction box is turned OFF.
1
4
