DFI INFINITY CS (V- M3598/N/0906) 1 CF 70
PREFACE
Manual Objectives
This manual shows you how to set up and use the Programmable Digital Meter.
Standard Procedures:
• Checking voltage jumpers, or changing voltage power
• Mounting the panel
• Selecting the input type
• Selecting a decimal point position
• Scaling with known loads (on-line calibration)
• Scaling without known loads
• Selecting ratiometric/non-ratiometric operation
• Displaying the filtered/unfiltered input signal
• Selecting a display color
• Setting the setpoint’s active band
• Selecting a latched or unlatched operation
• Setting setpoint deadbands
• Enabling/disabling setpoint changes
• Enabling/disabling the RESET button in the Run Mode
Optional Procedures:
• Setting input resolution
• Enabling/ disabling analog output
• Selecting analog output as current or voltage
• Assigning the output to net/gross reading
• Scaling analog output
Features with are for the “B” version which has three-color programmable “Big” LED display – All
segment characters shown are for the “B” version.
For first-time users: Refer to the QuickStart Manual for basic operation and set-up instructions.
Table A-1 Sections of the Manual
IF YOU WANT TO READ ABOUT: REFER TO SECTION
Unpacking; safety considerations 1 Introduction
Meter description and features 2 About the Meter
Main board power jumpers; panel mounting, sensor input, main power and
analog and relay output 3 Getting started
Input type; decimal point position; reading scale & offset; reading
configuration; display color; setpoint configuration; setpoint deadbands;
output configuration (analog output); analog output scaling; lock out
configuration; display brightness 4 Configuring the Meter
Display messages 5 Display Messages
Meter menu/sub-menu messages 6 Menu Configuration
Setpoint configuration messages 7 Setpoint Configuration Displays
Specifications 8 Specifications
Factory Preset Values 9 Factory Default Setup as Shipped
NOTES, WARNINGS and CAUTIONS
Information that is especially important to note is identified by three labels:
• NOTE
• WARNING
• CAUTION
• IMPORTANT
