DFI INFINITY CS (V- M3598/N/0906)
18
CF 70
4.5 Selecting a Display Color
Refer to Table 6-1 for a summary list of menu configuration.
Selecting Display Color is not active unless your meter is a Version “B”.
To select a display color, follow these steps:
1. Press
the
MENU button until the meter shows
.
2. Press
the
X/TARE button. The meter shows one of the following:
•
•
•
3. Press
the
S/NT/GRS button to scroll between available choices.
Press the MENU button to store your choice. The meter momentarily shows
, followed by the next menu
(Setpoint 1 Configuration). Or you can press the RESET button to abort and go back to the
menu.
4.6 Using Setpoint 1 Configuration
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 1 Configuration
is not active unless your meter has dual relay output capabilities. The LED’s will
display whether the
is active or not. You may use Setpoint 1 Configuration
for the following:
• To set the setpoint’s active band above or below your chosen value
• To select whether the setpoint operation is latched or unlatched
• Assigning setpoint values to the net or gross reading
4.6.1 Setting Setpoint 1’s Active Band
1. Press
the
MENU button until the meter shows
.
2. Press
the
X/TARE button. The meter shows one of the following:
•
= (Active above the setpoint) (Default)
•
= Active below the setpoint
3. Press
the
S/NT/GRS button to toggle between available choices.
4. Press
the
X/TARE button to select if Setpoint 1 is latched/unlatched or press the MENU button to store your
selection. The unit shows
.
4.6.2 Selecting if Setpoint 1 is Latched of Unlatched
1. Press
the
MENU button until
displays, then press the
X/TARE button twice.
or
Press the
X/TARE button from
.
The meter shows one of the following:
•
= Setpoint 1 to be unlatched (Default)
•
= Setpoint 1 to be latched
2. Press
the
S/NT/GRS button to toggle between available choices.
3. Press
the
X/TARE button to assign Setpoint 1 values to net or gross reading or press the MENU button to
enter
(Setpoint 2 Configuration).
4.6.3 Assigning Setpoint 1 Values to Net or Gross Readings
1. Press
the
MENU button until
displays, then press the
X/TARE button twice.
or
Press the
X/TARE button from
.
The meter shows one of the following:
