DFI INFINITY CS (V- M3598/N/0906) 21 CF 70
To reset latched alarms you must:
1. Input a signal OUT of the alarm zone
2. Then
press SETPTS and then, RESET button
4.10 Using Output Configuration
Refer to Table 6-1 for a summary list of menu configuration.
Output Configuration is not active unless your meter has analog output capabilities. The menu will display
whether analog output is present or not. Analog output must be ordered at time of purchase.
Use Output Configuration
to select the following:
• To enable or disable the analog output
• To select if the analog output is current or voltage
• To assign the output to the net or gross reading
4.10.1 Enabling or Disabling the Analog Output
To enable or disable the analog output, follow these steps:
1. Press
the MENU button until the meter shows .
2. Press the X/TARE button. The meter shows one of the following:
•
= (Analog output enabled) (Default))
•
= (Analog output disabled)
3. Press the S/NT/GRS button to toggle between available choices.
4. Press the X/TARE button to select analog output as current or voltage or press the MENU button to store your
selection and enter (Output Scale and Offset).
4.10.2 Selecting Analog Output as Current or Voltage
1. Press the MENU button until it shows , and then press the
X/TARE button twice.
or
Press the
X/TARE button from .
The meter will show one of the following:
•
= (Analog output=current) (Default)
•
= (Analog output=voltage)
2. Press the S/NT/GRS button to toggle between available choices.
3. Press the X/TARE button to select analog output or proportional control or press the MENU button to store
your selection and enter (Output scale and Offset).
4.10.3 Selecting Analog Output or Proportional Control
1. Press the MENU button until it shows , and then press the
X/TARE button twice.
or
Press the
X/TARE button from .
The meter shows one of the following:
•
= (Net Reading) (Default)
•
= (Gross Reading)
2. Press the S/NT/GRS button to toggle between available choices.
3. Press the MENU button to store your selection. The meter momentarily shows: , followed by
(Output Scale and Offset).
4.11 Using Output Scale and Offset
Refer to Table 6-1 for a summary list of menu configuration.
Output Scale and Offset is not active unless your meter has analog output capabilities. The menu will
display whether analog output is present or not. Output Scale and Offset scales your analog output to be
