= Setpoint 1 assigned to net reading (Default)
•
= Setpoint 1 assigned to gross reading
2. Press the S/NT/GRS button to toggle between available choices.
3. Press the MENU button to store your selection(s). The meter momentarily shows , followed by
(Setpoint 2 Configuration).
4.7 Using Setpoint 2 Configuration
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 2 Configuration is not active unless your meter has dual relay output capabilities. The LED’s will
display whether the is active or not. You may use Setpoint 2 Configuration for the following:
• To set setpoint’s active band above or below your chosen value
• To select whether the setpoint operation is latched or unlatched
• To assign setpoint values to the net or gross reading
4.7.1 Setting Setpoints 2’s Active Band
1. Press the MENU button until the meter shows .
or
2. Press the X/TARE button. The meter shows one of the following:
•
= (Active above the setpoint) (Default)
•
= (Active below the setpoint)
3. Press the S/NT/GRS button to toggle between available choices.
4. Press the X/TARE button to select if Setpoint 2 is latched/unlatched or press the MENU button to store your
selection. The meter shows .
4.7.2 Selecting if Setpoint 2 is Latched or Unlatched
1. Press the MENU button until displays, then press the X/TARE button twice.
or
Press the
X/TARE button from .
The meter shows one of the following:
•
= Setpoint 2 to be unlatched (Default)
•
= Setpoint 2 to be latched
2. Press the S/NT/GRS button to toggle between available choices.
3. Press the MENU button to store your selection(s). The meter momentarily shows , followed by
(Setpoint 1 Deadband).
4.7.3 Assigning Setpoint 2 Values to Net or Gross Readings
1. Press the MENU button until displays, then press the X/TARE button twice.
or
Press the
X/TARE button from .
The meter will show one of the following:
•
= Setpoint 2 assigned to net reading (Default)
•
= Setpoint 2 assigned to gross reading
2. Press the S/NT/GRS button to toggle between available choices.
3. Press the MENU button to store your selection(s). The meter momentarily shows , followed by
(Setpoint 1 Deadband).
4.8 Setting the Setpoint 1 Deadband
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 1 Deadband is not active unless your meter has dual relay output capabilities. The LED’s will
display whether the is active or not. The Setpoint 1 Default deadband is 0003. To change the deadband
(hysteresis) of Setpoint 1, follow these steps:
