CF 66 8 Rev. C 2/05
To leave SETUP mode and return to the RUN mode, press [EXIT].
3.5.3 Moving Through SETUP Menus and Menu Items
The following table shows how to move through menus and menu items, and how to display or change the setting
of a particular item.
Table 3-1: Navigating the Menus
Button Action
[UP] or [DOWN] Scroll through available menus, sub-menus or menu items
[ENTER] Select a menu, sub-menu or menu item
[EXIT]
If changing a setting…abandons changes to a menu item
otherwise…leaves the SETUP mode
To change the setting of a menu item:
Press [ENTER] to display the current setting, which is preceded by the ‘*’ character.
Press [UP] or [DOWN] until you see the setting you want. To abandon changes, press [EXIT]. To accept the new
setting and move to the next item, press [ENTER].
3.5.4 Exiting the SETUP Menu mode
To leave SETUP mode and return to the RUN mode, press [EXIT] at any time.
4.0 CHASSIS MODELS
4.1 Introduction
The DFI Series of Signal Conditioners/Indicators are available in several different chassis models. In general, each
chassis model operates in an identical fashion and can be ordered with any type of Input channels, Output
channels, or Virtual channels.
Input channels and Output channels are printed circuit boards that occupy a physical slot inside the instrument’s
chassis. 12-pin connectors are located on the rear panel to connect to each Input or Output Channel. Each
channel in the instrument is identified by a number (channel 01, channel 02, etc.).
A Virtual channel exists in software only; it does not occupy a physical slot inside of the instrument’s chassis.
There is no rear-panel connector for a Virtual channel. However, a Virtual channel does require a channel number.
4.2 Specifications
DFI 1550 DFI 1650 DFI 1650PT DFI SC3004
GENERAL
# Physical Channels 1 to 4 1 to 4 1 to 4 1 to 4
# Virtual Channels 8 8 8 8
Case Material Aluminum Aluminum Aluminum Aluminum
PHYSICAL
Form factor 3/8 DIN 3/8 DIN Suitcase 2U rack
Mounting Bench, panel or Rack Bench, panel or Rack Portable Rack
DISPLAY
# characters/line 16 16 16 20
# lines/display 2 2 2 4
# displays 1 1 1 1, 2 or 3
Display type Vacuum
Fluorescent
Vacuum
Fluorescent
Vacuum
Fluorescent
Vacuum
Fluorescent
ENVIRONMENTAL
Storage Temp. -30°C to 90°C -30°C to 90°C -30°C to 90°C -30°C to 90°C
