5.2 MANUAL MODE
There are three modes of operation: Manual mode, Program mode, and Run mode. Manual mode is used
to prepare the system to run a programmed method, or to perform tasks that do not require a programmed
method, such as simple pumping tasks. When you first turn on the system, the Manual mode’s Pump
Control screen is displayed so that you can purge the system, calibrate the pump, and select the buffers for
your application. To select other Manual mode functions, use the Instrument keys on the front panel. The
top line of each screen in Manual mode displays the following:
• Method name: The name of the currently loaded method. Changing the method name is done in
Program mode.
• Mode of operation: The mode is also indicated by the key’s LED being lit.
5.2.1 Manual Mode Operation of the Pump
Table 6 discusses each of the functions available in Manual mode operation of the pump. An overview of
Manual mode operation of the Pump is shown in Figure 15.
Table 6.
Manual Mode Operation: Pump
Reference Description
To begin Manual mode operation of the pump:
a.
From the Mode keys select Manual.
b. From the Instrument keys select Pump.
c. The main menu for manual mode operation of the pump is
shown below.
Main Menu screen: The display shows the following:
•
Flow: The current flow rate set for the pump. The arrow
shows the direction of flow.
• UV: The current UV reading.
• Buffer A through E or %B: The currently selected buffer or
a mixture, as specified by the amount of buffer B.
• Cond: The current Conductivity reading.
Description of the soft key choices follows.
34
System Operation
Method: <> Manual Operation
–> Flow: 1.00 ml/min UV: 0.0111 AU
Buffer: A Cond: 0.000 mS
START PURGE FLOW BUFFER
MP
M1 M2 M3 M4
Manual Pump
