6 = Barometric Pressure Sensor
7 = Rudder Angle Sensor
Note
Do not select the same number on more than one linear input, otherwise the
selection will be ignored (no function can be connected to more than one
input).
5.3.
ANALOGUE INDICATORS
5.3.1
Options Available
Type of Indicator Scale B&G Part Number
Boat Speed 0 to 12.5 knots 215-HL-019
Boat Speed 0 to 25 knots 215-HL-058
Boat Speed 0 to 50 knots 215-HL-154
Wind Speed 0 to 25
metres/second
215-HL-071
Wind Speed 0 to 50 knots 215-HL-022
Wind Direction 360
°
wind direction 215-HL-016
Magnified Wind
Direction
40-0-40 degrees 215-HL-017
Head/Lift Trend* 40-0-40 degrees 215-HL-152
Depth 0 to 200 metres 215-HL-025
Depth 0 to 100 Ft/fathoms 215-HL-026
Compass Card 360
°
215-HL-142
Cross Track
Error
(XTE)
10-0-10 nautical miles 215-HL-119
Off Course* 40-0-40
°
215-HL-151
Heel Angle 40-0-40
°
215-HL-160
Rudder Angle 40-0-40
°
215-HL-158
Table 5.1 - Analogue Indicators Available
Up to four different types of analogue indicators, selected from the range
listed in Table 5.1 can be added to the system. If more analogues are
required then the Expansion Unit can be used, allowing another four
indicators to be added to the system.
Note
