Operating Instructions 25
03/28/2007 407-158M
PFC1600 Pumping
Configuration:
YP2425 with 3-inlet “Hi-Rate” Manifold
PFC1600 Tank Cart
Refer to Figure 24 on page 49
1. Set valve at 1600 gallon tank discharge to feed
pump.
2. Set CFM “Fert.Pump” switch to ON and begin
planting.
The ground drive pump on the cart will pump fertilizer
to all three planter manifold sections when planter is
lowered and cart is in motion, unless commanded off
by the seed monitor or CFM “Fert.Pump” switch.
PFC1600 Point Row Pumping from 1600
If it is necessary to disable fertilizer application for one
or two planter sections, such as for point rows, use the
Clutch Folding Module switches. When you disable the
clutches for any seed meters, the monitor also closes
the manifold valve for that planter section. This pro-
vides automatic fertilizer control for point rows.
Whenever one or two of the cart manifold valves (#1,
2, 3) are closed, the bypass valve (#4) is open. This
prevents over-pressure in the planter manifolds. The
bypass line
is connected to the cart pump inlet at
all times when pumping from the 1600 gallon tank
(valve
set to pump). The bypass is also connected
to the tank discharge line.
12
16
12
