24
407-158M 03/28/2007
PFC2000 Pumping From 1600 Only
Configuration:
PFC2000 Tank Cart
YP2425 with 3-inlet “Hi-Rate” Manifold
all 3 inlets and section booms in use on planter
Refer to Figure 23 on page 48
1. Set 400 gallon inlet and outlet valves to
OFF.
2. Set valve at 1600 gallon tank discharge to feed
pump.
3. Set pump inlet selector valve to 1600 tank.
4. Set CFM “Fert.Pump” switch to ON and begin
planting.
The ground drive pump on the cart will pump fertilizer
to all three planter manifold sections when planter is
lowered and cart is in motion, unless commanded off
by the seed monitor or CFM “Fert.Pump” switch.
PFC2000 Point Row Pumping from 1600
If it is necessary to disable fertilizer application for one
or two planter sections, such as for point rows, use the
Clutch Folding Module switches. When you disable the
clutches for any seed meters, the monitor also closes
the manifold valve for that planter section. This pro-
vides automatic fertilizer control for point rows.
Whenever one or two of the cart manifold valves (#1,
2, 3) are closed, the bypass valve (#4) is open. This
prevents over-pressure in the planter manifolds. The
bypass line
is connected to the cart pump inlet
when pumping from the 1600 gallon tank.The bypass
is also connected to the tank discharge line.
13 14
12
15
16
