Great Plains Manufacturing, Inc. Maintenance and Lubrication 71
07/09/2009 401-226M
Cleaning Out Meters
Precision Meter
Refer to Figure 87 (finger meter shown, but step is identical)
1.
Place a bucket or pan under meter to catch any seed
during cleanout.
2. Slide the retaining ring up and remove the seed
hose.
Refer to Figure 88
3.
Pull cleanout door away from the opening and allow
seed to fall.
4. Remove the seed meter wheel for thorough cleaning.
See “Meter Removal” on page 54 for more informa-
tion.
Finger Pickup Meter
Refer to Figure 87
1.
Place a bucket or pan under meter to catch any seed
during cleanout.
2. Slide the retaining ring up and remove the seed
hose.
Refer to Figure 89
3.
Pull cleanout door away from the opening and allow
seed to fall.
Figure 87
Remove Hose Retaining Ring
22883
Figure 88
Open Cleanout Door
22885
Figure 89
Finger Meter Cleanout Door
21920
