Great Plains Manufacturing, Inc. Adjustments 59
07/09/2009 401-226M
Finger Meter Adjustments
The finger pick up meter has an adjustable brush, and
alternate inserts are available for the backing plate. The
brush has been pre-set to the optimum setting for most
seed sizes. The factory-installed insert is the “A” insert.
Optimum planting speed is 4 1 ⁄
2
to 5 miles per hour.
Excess speed results in poor spacing performance due
to seed tube bounce. Excess speed may also result in
improper depth control due to row unit bounce.
Always pay attention to your planter monitor. Compare
actual seed usage to your estimates.
Fine-tune your planter by thoroughly checking all key
components including: seed tubes, chains, sprockets,
tire pressure, seed monitor, double disk openers, gauge
wheels, seed firmer, closing wheels, parallel arms, and
the row unit itself.
Finger Meter Brush Adjustment
The brush reduces or eliminates “doubles” (delivering
two seeds per finger), but if set too aggressively can
cause “skips” (delivering no seed on some fingers). As
needed, adjust for minimal doubles and skips.
Note: These instructions describe the current finger pick-
up meter shipped with new Great Plains planters,
which has an integrated adjustment lever for the
brush. If you have the previous model meters, ad-
justed by screwdriver rather than lever, rely on
counting detents to determine the setting. Not all
have 9 detents.
Refer to Figure 77
The adjustable brush provides additional flexibility to
accommodate a wide range of seed sizes. Use lever (L)
to gently rotate the brush into position.
The settings range from 1 to 5 with detents at each half
step, for a total of 9 detents. Although the numbers are
molded into the meter housing, only “1” and “5” may be
visible.To ensure consistency, rotate the lever fully
counter-clockwise (1), and count detents as you advance
it to the desired setting. Use the general guidelines in the table below to adjust
the brush position to your seed size and shape. The
numbers listed correspond to the numbers printed on the
outer housing of your meter. If there is a decal on your
meter, its units are seed size in pounds per 80,000 seed
bag. The table below includes seeds per pound.
Figure 77
Finger Meter Brush Lever
25276
5
1
4
3
2
L
Brush
Setting
Seed
Shape
Bag Weight
(80,000 seeds)
Seeds Per
Pound
Comment
1
rounds 65 lbs 1231 or less Use this setting for larger seeds
flats 45 lbs 1778 or less
2
rounds 55 lbs 1455 Use this setting for 1231-1355 round seeds/lb.
rounds 65 lbs 1231
flats 35 lbs 2286 Use this setting for 1778-2286 flat seeds/lb.
flats 45 lbs 1778
3
rounds 45 lbs 1778 Use this setting for 1455-1778 round seeds/lb.
rounds 55 lbs 1455
flats 45 lbs 1778 or more Use this setting for 1778 and smaller flat seeds
4
rounds 35 lbs 2286 Use this setting for 1778-2286 round seeds/lb.
rounds 45 lbs 1778
5 rounds 35 lbs 2286 or more Use this setting for 2286 and smaller round seeds
