Great Plains Manufacturing, Inc. Operating Instructions 23
07/09/2009 401-226M
Refer to Figure 16 through Figure 19 on page 21.
9.
Remove lift cylinder transport lock channels from
gauge wheels and center frame. Return transport
lock channels to storage area.
10. Activate lift hydraulics and lower planter.
11. Set electronic valve selector switch in tractor to
“MARKER” to activate marker hydraulics.
12. Switch drive-line clutches on.
Changing the Seed Box or Hopper
1. Shut off fan before changing boxes.
2. Park the planter on level ground with enough room to
maneuver a tractor with front-end loader around it.
3. Place tractor in park, shut off engine, and remove the
key.
4. Close the slide gate.
Refer to Figure 23
5.
Remove the walkboard lock pin .
Refer to Figure 24
6.
Swing walkboard all the way to the right.
Note: If planter is lowered, walkboard will stay open by
itself once fully opened.
Figure 23
Walkboard Lock Pin
24010
1
1
Figure 24
Walkboard Open
24005
2
2
2
