Table 4A — Capacity Control Steps, 040-070
UNIT
30GN
CONTROL
STEPS
LOADING SEQUENCE A LOADING SEQUENCE B
%
Compressors
%
Compressors Displacement Displacement
(Approx) (Approx)
040 (60 Hz)
A1†,B1
1 25 A1* — —
2 50 A1 — —
3 75 A1*, B1 — —
4 100 A1,B1 — —
040 (60 Hz)
A1†,B1**
1 25 A1* 25 B1*
2 50 A1 50 B1
3 75 A1*,B1 75 A1,B1*
4 100 A1,B1 100 A1,B1
040 (50 Hz)
045 (60 Hz)
A1†,B1
1 24 A1* — —
2 47 A1 — —
3 76 A1*,B1 — —
4 100 A1,B1 — —
040 (50 Hz)
045 (60 Hz)
A1†,B1**
1 24 A1* 37 B1*
2 47 A1 53 B1
3 61 A1*,B1* 61 A1*,B1*
4 76 A1*,B1 84 A1,B1*
5 100 A1,B1 100 A1,B1
040 (50 Hz)
045 (60 Hz)
A1†,B1**
1 — — 21 B1††
2 — — 37 B1*
3 — — 53 B1
4 — — 68 A1,B1††
5 — — 84 A1,B1*
6 — — 100 A1,B1
045 (50 Hz)
050 (60 Hz)
A1†,B1
1 31 A1* — —
2 44 A1 — —
3 87 A1*,B1 — —
4 100 A1,B1 — —
045 (50 Hz)
050 (60 Hz)
A1†,B1**
1 31 A1* 38 B1*
2 44 A1 56 B1
3 69 A1*,B1* 69 A1*,B1*
4 87 A1*,B1 82 A1,B1*
5 100 A1,B1 100 A1,B1
045 (50 Hz)
050 (60 Hz)
A1†**,B1
1 18 A1†† — —
2 31 A1* — —
3 73 A1††,B1 — —
4 87 A1*,B1 — —
5 100 A1,B1 — —
045 (50 Hz)
050 (60 Hz)
A1†**,B1**
1 18 A1†† — —
2 31 A1* — —
3 44 A1 — —
4 56 A1††,B1* — —
5 73 A1††,B1 — —
6 87 A1*,B1 — —
7 100 A1,B1 — —
045 (50 Hz)
050 (60 Hz)
A1†,B1**
1 — — 20 B1††
2 — — 38 B1*
3 — — 56 B1
4 — — 51 A1*,B1††
5 — — 64 A1,B1††
6 — — 82 A1,B1*
7 — — 100 A1,B1
*Unloaded compressor.
†Compressor unloader, standard.
**Compressor unloader(s), accessory.
††Two unloaders, both unloaded.
