Table 8 — Accessing Functions and Subfunctions

OPERATION

KEYPAD

DISPLAY

EXPANSION

ENTRY

RESPONSE

To access a function, press

RESET

RESET SETPOINTS

subfunction no. and function
name key. Display shows sub-
function group.
To move to other elements,
scroll up or down using arrow
keys. NOTE: These
displays do not show if
control is not configured
for reset.

CRT1 x

COOL RESET AT 20 MA

CRT2N x

COOL RTEMP (NO RESET)

CRT2F x

COOL RTEMP (FULL RESET)

CRT2D x

COOL DEGREES RESET

When the last element in a
subfunction has been displayed,
the first element is repeated.

RESET

RESET SETPOINTS

CRT1 x

COOL RESET AT 20 MA

To move to next subfunction
it is not necessary to use
subfunction number. Press
function name key to ad-
vance display through all
subfunctions within a
function and then back
to the first.

DEMAND

DEMAND LIMIT SETPOINTS

TIME

CURRENT TIME AND DAY OF
WEEK

SETPOINT

UNIT SETPOINTS

To move to another function,
either depress function name
key for desired function
(display shows the first
subfunction),

X ALARMS

THERE ARE n ALARMS

Access a specific sub-

STAGE

CAPACITY STAGING
INFORMATION

function by using the sub-
function number and the
function name key.

Table 9 — Keypad Directory

STATUS

SUBFUNCTION

KEYPAD ENTRY

DISPLAY

COMMENT

1 AUTOMATIC DISPLAY

Refer to Automatic Display Operation/Default Display section on page 25.

2 ALARMS/ALERTS

X ALARMS

Number of Tripped Alarms/Alerts

R S AL

Reset all Alarms/Alerts

ALARM* X

}

Displays Tripped Alarms/Alerts

ALARM* X

To toggle between inputs (Yes/No) Press:

(no) or

(yes)

3 MODES

X MODES

Number of Modes in Effect

X MODE

}

Displays Mode in Effect

X MODE
