Page 26

CUTMASTER 42 INSTALLATION
Installation 3-6 Manual 0-5171
3.06 Input Wiring Specifications
CUTMASTER 42 Input Power Requirements
Input
Power Input
Current Input Current Input Suggested Sizes (See Note)
Voltage
Freq.
(kVA)
Max (Amps)
Ieff (Amps)
Fuse (Amps)
(Volts-AC)
(Hz)
1-Ph
1-Ph
1-Ph
1-Ph
120
50/60
3.3
27.5
15
20
208
50/60
5.0
24
15.4
20
230
50/60
5.0
21.4
13.5
20
240
50/60
5.0
20.8
13
20
Line Voltages with Suggested Circuit Protection
Motor start fuses or thermal circuit breakers are recommended for this application. Check local requirements
for your situation in this regard.
NOTE
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
The suggested sizes are based on flexible power cable with power plug installations.
Cable conductor temperature used is 167° F (75° C).
